SPECIFICATIONS
Specifications
a CD section
Audio (CD-DA)
Sampling frequency:
No. of channels:
Frequency response:
Headphones output level:
Pickup
Light source:
Wavelength:
MP3
Supported bit rates:
Supported sampling frequency:
Maximum number at items
44.1 kHZ
2 channels (lelt and right, stereo)
20 to 20.000 H/ (0.5 dB to -7 dB)
RMS max 8 mW+8 mW/ts 0
(adjustable)
Semiconductor laser
780 nm
32 kbps to 320 kbps
(128 khps is recommended)
48 kHz/44.1 kHflSZ kHz
(total no. at albums and tracks):999
Maximum album levels:
0 RADIO section
Frequency
Radio frequency:
FM;
AM;
IF:
FM:
AM:
Audio
Selectivity:
FM:
AM;
Sensitivity:
AM;
0 General
Operational temperature range:
Rechargeable temperature range:
100
87.5 -108.0 MHZ
(0 05 MHz steps)
522 -1829 kHz (9 kHz steps)
10.7 MHZ
459 kHz
42 (58
7A kH7 (6 dB)/21dB (9 kH7)
7 LIV/0.5 mW Output (S/NBO dB)
707 pV/m/OE rnW output (MAX)
0 v 40 degree
5 - 40 degree
Power supply:
Dc input (AC adapter, incluec);
AC adaptor input;
Power consumption:
DC 4.5 V
AC 220 ~ 230 V, 50/60 HZ
MP3 discCD-DA/ RADIO
AC adaptor; 4 W. 4 W/3.7 W
Recharging; 5.9 W
Playing time:
Using on a llal stable surface at 25 degree, EC) is oil. Hold is on, Anti-
skip is on POSthD-DA), recommended bit rate (MP3: 128 kbps) and
Digital Flo-master is off (MP3). Play lime are in hours and
approximate.
Battery used: MP3 dlsc/CD-DA disc/ RADtO (FM BAND)
2 alkaline batteries (LR03);
Approx. 41/23/31 h
2 alkaline batteries (LRS):
Approx. 100/52/75 h
4 alkaline batteries (2 LR03 + 2 L85);
Approx. 141/75/106 h
2 optional rechargeable batteries:
Approx. 28/15/21 h
2 optional rechargeable and 2 alkaline batteries (LRS);
Approx. 128/67/96 h
I The play time may be less depending on the operating conditions.
- Play time will be considerably reduced when playing CDVRW.
Recharging time: Approx. 3.5 to 4.5 h
Dimensions (WxHxD): 156.7x20.5x136.7 mm
Mass: 194.5 g (with batteries)
172.5 9 (without batteries)
Notes: Specrlications are subject to change without notice
Mass and dimensions are approximate.
Note on CD-R and CD-RW
For CD-DA format. use a music disc and finalize it after recording.
The unit may not be able to play some discs due to the condition of
the recording.
* A process performed alter recording that enables CD-Fi/CDRW
players to play audio CD-R and CDvRW,
l
A WARNING
This service intormation is designed for experienced repair technicians only and is not deSIgned for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be servrced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service iniormation by anyone else could result in serious iniury or death.
Panasonic
1. Accessories
' AC adaptor
(RFEA419E-M)................................................1 pc.
' Stereo earphones
(LOBABOOOO183)...........................................1 pc.
