panasonic sl ct 490 owners manual

Extracted text from panasonic sl ct 490 owners manual (Ocr-read)


Page 1

Battery indicator This indicator flashes when the batteries are almost out of power. Power is cut off completely a short while later. Rechargeable batteries:Recharge batteries. Dry-cell batteries:Replace batteries with new ones. Note! ≥The length of time the unit will continue to operate be- tween when the battery indicator starts flashing and when the power is cut off differs depending on the type of batteries used. ≥The battery indicator may not be displayed if recharge- able batteries other than those designated by Panasonic are used. Using the car adaptor (not included) Be sure to obtain the car adaptor (SH-CDC9), available as an optional accessory. The car adaptor can be used to recharge the units bat- teries while in the car. 2 Power Supply Preparations Refer to the specifications (page 8) for information on operating times when using rechargeable batteries or dry cell batteries. CAUTION:Use only car adaptor, Model: SH-CDC9 manufac- tured by Matsushita Electric Industrial Co., Ltd. Removing batteries Push up on the battery in the direction indicat- ed by the arrow. Then lift it out. If the battery lid comes loose Slide the lid back into place horizontally. OPENOPEN If the unit malfunctions or freezes during use, disconnect the power source (the AC adaptor or batteries). Re-connect the power source and contin- ue operation. This function causes the unit to ignore short, accidental button presses. (The disc lid can still be opened and closed.) The HOLD function prevents the following:≥The unit is powered on accidentally when not in use, causing the batteries to run down. ≥A button is accidentally pressed during play, interrupt- ing the operation. To use the HOLD functionSet [HOLD] to the HOLD position. The unit and wired remote control have HOLD func- tions, each of which works independently. ( indication When the main unit is in HOLD mode, pressing any but- ton causes the indication ( to appear on the dis- play. When the unit is powered off The ( indication appears only when [1/;] (main unit) is pressed. Before operating the buttons Be sure to move [HOLD] to release the unit from the HOLD mode. HOLD HOLD EQ HOLD HOLD HOLD VOLM E M O R YR E C A L LE QM O D E OPEN Ë H O L D HOLD mode HOLD function Battery indicator S-XBS C Using the AC adaptor (not included) Use only the recommended AC adaptor. Using other adaptors can cause overheating which can lead to fire. Connect the AC adaptor. Conserving powerTo save power when the unit is not to be used for a long time, unplug the AC adaptor from the household AC outlet. Reprogram tracks if necessary before use. Note!Turn the unit off before connecting or disconnecting the AC adaptor. Using the rechargeable batteries (not included) Obtain the optional rechargeable batteries. Make sure to recharge the batteries before using them. The unit cannot be used to charge rechargeable batter- ies other than those specially designed for it. Optional batteries: P-3GAVA/2B Charging procedure 1 Insert the special rechargeable bat- teries into the unit. HOLD Ë DC IN 4.5V DC IN jack (KDC IN 4.5 V) Side panel of the unit Household AC outlet AC adaptor For U.S.A To order the optional AC adaptorRP-AC46contact 1- 800-332-5368 or web site (http://www.panasonic.com). For Canada Be sure to obtain the optional AC adaptor RP-AC46. it is available through your Panasonic dealer. Note!≥Rechargeable batteries have a service life of approxi- mately 300 charge-discharge cycles. The batteries have reached the end of their operational life if they last for a noticeably shorter time after recharging, or if they cannot be recharged at all. Replace the batteries. ≥Recharging may only be performed when the unit is powered off. ≥The AC adaptor and rechargeable batteries may be- come warm while recharging is in progress. This is not a malfunction. ≥Leaving the AC adaptor connected can cause the bat- teries to go flat. After recharging the batteries and dis- connecting the AC adaptor from the AC power outlet, ensure you disconnect the AC adaptor from the units [K DC IN 4.5 V] terminal. ≥Never mix dry cell and rechargeable batteries. ≥Turn the unit off before replacing the recharge- able batteries. 2 Connect the AC adaptor.(Refer to Using the AC adaptor.) Recharging starts and the H charging indicator flashes on the units display. The indicator goes out when charging is complete. 3 When charging is complete, unplug the AC adaptor from the household AC outlet and DC IN jack. Using the dry cell batteries (not included) After disconnecting the AC adaptor, insert two LR6, AA, UM3 alkaline batteries. The procedure for inserting and removing dry cell batteries is identical to that for rechargeable batter- ies. This system deals with skipping in a variety of ways: ≥The thinner and lighter construction makes the unit less susceptible to vibration. ≥An anti-skip mechanism prevents skipping caused when play speed changes due to swinging of the unit. ≥A recovery system immediately returns the laser pick- up to its original position if it is knocked off the track by a strong shock. ≥Anti-skip (max. 48 seconds) memory fills in interrup- tions caused by bumps and vibrations. The anti-skip system works automatically while the system is on and cannot be canceled. .When bumps continue repeatedlyThe elapsed playing time disappears and sound is inter- rupted. Note! ≥While the system is on, the disc rotates at a higher rate than usual in collecting extra audio data. This could result in a slight increase in disc rotation noise. ≥The anti-skip memory compresses digital signals. S-XBS Anti-Skip System OPEN OPENOPEN 1 2 3 + - HOLD mode ReleaseRelease

Page 2

Button Display/reference Operation To pause play To stop play To turn off the unit Skip forward/ backward (skip function) Rapid forward/ backward (search function) Off mode Stop mode 2 14 5 HOLD 3 HOLD Ë OPEN VOL M E M O R YR E C A L LEQ MODE OPEN S-XBS VOL C VOL S-XBS C L R VOL For your reference: ) indication This indication appears for about 30 seconds if [1/;] is pressed when no disc is loaded in the unit or if the disc is not properly secured. * indicationThis indication appears for about 10 minutes when the cover is opened. (However, the indication does not ap- pear when the unit is powered off.) Removing discs1 Press [∫] to stop play and disc rotation. 2 Slide [OPEN1] to open the lid. 3 Once the disc has stopped, lift the disc out with your finger. Do not stop the disc by hand or try to remove it before it stops rotating. This can damage CDs. Note! Never insert foreign objects into the unit. Auto-off functionIf you leave the unit in stop mode for about 10 minites (30 seconds if disc is not loaded), it turns off to save the batteries. 3 Sequential Play Basic Play Elapsed playing time of each trackTrack number in play Close the lid Plug type: 3.5 mm (1/8 in.) stereoDecrease Increase ≥During program play (page 4), these buttons are used to skip forward or backward through the programmed sequence of tracks. ≥You cannot skip to tracks that have been played in random or random repeat play (page 4). ≥During program play, 1-track repeat play, random play and random repeat play (page 4), search op- eration is limited to the current track only. Press during play. Press during play. Press during stop mode. Press during play. (Press [:] twice to skip to the beginning of the previous tracks.)Press again to restart play. Press and hold during play. Backward Forward C C C Total number of tracks Total playing time Resume function notes≥Opening the lid while in the stop mode or replacing the disc while in the off mode cancels the function. (It may re- main active if you replace a disc in the off mode.) ≥Play may resume from the beginning of the next track if you stopped play near the end of a track. ≥The resume function works automatically and cannot be turned off.No indicator is shown. Resume functionPlay starts from the beginning of the current track the next time you press [1/;]. Note on CD-R and CD-RWThis unit can play CD-DA format audio CD-R and CD-RW that have been finalized §upon completion of recording. It may not be able to play some CD-R or CD-RW due to the condition of the recording. §Finalizing is a process that enables CD-R/CD-RW players to play audio CD-R and CD-RW. Follow steps 1–5.In step 2:Connect the clip headphones/ stereo earphones and wired remote control to the headphone jack [Ë] . (Plug in firmly.) In step 5:The volume range is 0-25. Press and hold to change the volume successively. The volume changes when pressed while the level is displayed. If any other display is shown, it changes to show the current level. (The volume returns to 10 when you disconnect the power source.) ≥Play stops automatically when all the tracks have been played. ≥If the unit has been connected to the car audio system, set this units volume to 10, then adjust the volume level on the system.Label must face upward. Press near the center so the disc clicks firmly into place.
