Panasonic sh ge 90 owners manual

Page 2

We thank you for selecting this product and welcome
you to the growing family of satisfied Technics prod-
uct owners around the world.

We feel certain you will get maximum enjoyment

from this new addition to your home.

Please read these operating instructions carefully,
and be sure to keep them handy for convenient ref-
erence.

Contents

Accessories ................................ 2
For United Kingdom ......................... 2
Suggestions for Safety ...................... 3
Connections ................................ 4
Front Panel Controls and Functions . 5
Before Adjusting the Sound . . . 7
Changing the Tone Quality ................... 8
Changing the Simulated Listening

Environments ............................. 11

(For areas except continental Europe, United Kingdom and Australia)

Adjusting the Level of the Specific
Frequency ................................ 14
Memorizing Your Own Sound . .. .15

Using the KARAOKE" Function . .16
Making a Recording ......................... 18
About the Spectrum Display ................. 19
Maintenance ................................ 1 9
Troubleshooting Guide ............. Back cover
Technical Specifications ............ Back cover

CAUTION:
The AC voltage is different according to the area.

Be sure to set the proper voltage in your area before use.

(For details, please refer to the page 4.)

Accessories

OStereo connection cables ............ 2

IAC power supply cord . . .

............ 1 cPowerplugadaptor.................1
(For areas except Continental Europe,

United Kingdom and Australia)

Q

Note: The configuration of the AC power supply cord differs according to area,

For United Kingdom

(EB area code model only)
The EB indication is shown on the serial number tag.

Important

THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCOR-
DANCE WITH THE FOLLOWING CODE.

BLUE: NEUTRAL

BROWN: LIVE

As the colours of the wires in the mains lead of this apparatus may
not correspond with the coloured markings identifying the terminals
in your plug proceed as follows. The wire which is coloured BLUE
must be connected to the terminal which is marked with the letter N
or coloured BLACK.

The wire which is coloured BROWN must be connected to the
terminal which is marked with the letter L or coloured RED.

Under no circumstances must either of the above wires be con-
nected to the earth terminal of a three pin plug.
