Panasonic sb pf 760 gc service manual

This is the 11 pages manual for panasonic sb pf 760 gc service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 11
panasonic sb pf 760 gc service manual

Extracted text from panasonic sb pf 760 gc service manual (Ocr-read)


Page 1

1 System Combination 1.1. System Breakdown Note : The tables below show the breakdown for speaker combinations used in main unit systems. System SC-VK760GC-K Music center SA-VK760GC-K Front speaker SB-PF760GC-K Surround speakers SB-PS760GC-K Center speaker SB-PC760GC-K Subwoofer SB-WVK760GC-K System SC-VK760EE-K Music center SA-VK760EE-K Front speaker SB-PF760GC-K Surround speakers SB-PS760GC-K Center speaker SB-PC760GC-K Subwoofer SB-WVK760GC-K System SC-VK760GCPK Music center SA-VK760GCPK Front speaker SB-PF760GC-K Surround speakers SB-PS760GC-K Center speaker SB-PC760GC-K Subwoofer SB-WVK760GC-K System SC-VK760GCSK Music center SA-VK760GCSK Front speaker SB-PF760GC-K Surround speakers SB-PS760GC-K Center speaker SB-PC760GC-K Subwoofer SB-WVK760GC-K System SC-VK760GCTK Music center SA-VK760GCTK Front speaker SB-PF760GC-K Surround speakers SB-PS760GC-K Center speaker SB-PC760GC-K Subwoofer SB-WVK760GC-K System SC-VK760GS-K Music center SA-VK760GS-K Front speaker SB-PF760GC-K Surround speakers SB-PS760GC-K Center speaker SB-PC760GC-K Subwoofer SB-WVK760GC-K 2 SB-PF760 GC

Page 2

2 Assembling and Disassembling ATTENTION SERVICER Some chassis components may have sharp edges. Be careful when disassembling and servicing. 1. This section describes procedures for checking the operation and replacing the main components. 2. For reassembly after operation checks or replacement, reverse the respective procedures. Specia l reassembly procedures are described only when required. 3. Select items from the following index when checks or replacement are required. 4. Refer to the Parts No. on the page of Parts Locatio n and Replac ement Parts List (Section 5), if necessary. Below is the list of disassembly sections Disasse mbly of Front Panel Disasse mbly of Tweeter (SP1) Disasse mbly of Woofer (SP2) 3 SB-PF760 GC
