1 System Combination 1.1. System Breakdown Note : The tables below show the breakdown for speaker combinations used in main unit systems. System SC-VK660EE-K Music center SA-VK660EE-K Front speaker SB-PF660GC-K Subwoofer SB-WVK660GC-K System SC-VK660GC-K Music center SA-VK660GC-K Front speaker SB-PF660GC-K Subwoofer SB-WVK660GC-K System SC-VK660GCSK Music center SA-VK660GCSK Front speaker SB-PF660GC-K Subwoofer SB-WVK660GC-K System SC-VK660GCTK Music center SA-VK660GCTK Front speaker SB-PF660GC-K Subwoofer SB-WVK660GC-K System SC-VK660GN-K Music center SA-VK660GN-K Front speaker SB-PF660GC-K Subwoofer SB-WVK660GC-K System SC-VK660GS-K Music center SA-VK660GS-K Front speaker SB-PF660GC-K Subwoofer SB-WVK660GC-K 2 SB-PF660 GC
Page 2
2 Assembling and Disassembling ATTENTION SERVI CER Some chassis components may have sharp edges. Be careful when disassembling and servicing. 1. This section describes procedures for checking the operation and replacing the main components. 2. For reassembly after operation checks or replacement, reverse the respective procedures. Specia l reassembly procedures are described only when required. 3. Select items from the following index when checks or replacement are required. 4. Refer to the Parts No. on the page of Parts Locatio n and Replac ement Parts List (Section 5), if necessary. Below is the list of disassembly sections - Disasse mbly of Rear cabinet assembly - Disasse mbly of Tweeter (SP1) - Disasse mbly of Woofer (SP2) 2.1. Disassembly flow chart The following chart is the procedure for disassembling the casing and inside parts for internal inspection when carrying out the servicing. To assemble the unit, reverse the steps shown in the chart as below. 3 SB-PF660 GC
