panasonic sb maf370 service manual

Extracted text from panasonic sb maf370 service manual (Ocr-read)


Page 1

2 1 Specifications Front Speakers (SB-MAF370PUK) Ty p e2 way 3 speaker system (closed) Speaker unit(s) Woofer 10 cm cone type x2 Tweeter 6 cm cone type x1 Impedance 3 Ω Output sound pressure 87 dB/W (1 m) Frequency range 100 Hz to 30 kHz (-16 dB) 105 Hz to 27 kHz (-10 dB) Dimensions (W x H x D) 360 mm x 147 mm x 243 mm Mass Aprox. 2.9 kg Subwoofer Speaker (SB-MAW370PUK) Ty p e 1 way, 1 speaker system (Bass reflex) Speaker unit(s) Super Woofer (Low) 25 cm Cone type Impedance 6 Ω Output sound pressure 88 dB/W (1 m) Frequency range 25 Hz to 250 Hz (-16 dB) 30 Hz to 200 Hz (-10 dB) Dimensions (W x H x D) 360 mm x 402 mm x 310 mm Mass Aprox. 8.2 kg Subwoofer Speaker (SB-MAY370PUK) Ty p e 1 way, 1 speaker system (Bass reflex) Speaker unit(s) Super Woofer (Medium-Low) 25 cm Cone type Impedance 3 Ω Output sound pressure 87 dB/W (1 m) Frequency range 25 Hz to 250 Hz (-16 dB) 30 Hz to 200 Hz (-10 dB) Dimensions (W x H x D) 360 mm x 402 mm x 310 mm Mass Aprox. 8.2 kg Notes: 1. Specifications are subjec t to change without notice. Mass and dimensions are approximate. 2. Total harmonic distortion is meas ured by the digital spectrum ana- lyzer.

Page 2

3 2 Disassembly and Assembly Instructions Caution Note:- This section describes procedures for checking the operation and replacing the main components. - For reassembly after operation checks or replacement, reverse the respective procedures. - Special reassembly procedures are described only when required. - Before carrying out the disassembly process, please ensure all the safety precautions & procedures are followed. - During the disassembly and/or assembly process, please ha ndle with care as there may be chassis components with sharp edges. - During replacement of component parts, pleas e refer to the section of Replacement Parts List as described in the service man - ual. - Select items from the following indexes w hen disassembly or replacement are required. Front Speakers (SB-MAF370PUK) - Disassembly of Front Panel Block - Disassembly of Tweeter Speaker (SP1) - Disassembly of Full Range Speaker (SP2) Woofer Speaker (SB-MAW370PUK), (SB-MAY370PUK) - Disassembly of Front Panel Block - Disassembly of Woofer Speaker (SP21) - Disassembly of Lighting Wire P.C.B. Assembly
