Panasonic sa max5000pn max5000ps

Page 1

PSG1603007CE

Service Manual

SB-MAX5000

SB-MAX5000

Remote
Control

CD Stereo System

Model No. SA-MAX5000PN

SA-MAX5000PS

Product Color: (K)...Black Type

Please refer to the original service manual for:
0 CD Mechanism Unit Order No. PSG1303059AE

0 Speaker system SB-MAX5000PN/PS, Order No. PSG1603009CE

A WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

IMPORTANT SAFETY NOTICE

There are special components used in this equipment which are important for safety. These parts are marked by A in the Schematic
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturers specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of

manufacturer.

TABLE OF CONTENTS

1 Safety Precautions --------
1.1. General Guidelines-
1.2. Before Repair and Adjustment
1.3. Protection Circuitry -------
1.4. Safety Parts Information

2 Warning -----------------------------
2.1. Prevention of Electrostatic Discharge (ESD)

to Electrostatioally Sensitive (ES) Devices--
2.2. Precaution of Laser Diode --------------------
2.3. General description about Lead Free Solder

(PbF) ---------------------------------------------------------- 7
2.4. Handling Precautions for Traverse Ass'y ------------ 7
2.5. Grounding for electrostatic breakdown

prevention -

3 Service Navigation

Panasonici

3.1. Service Information -----------
3.2. Software Update Procedure
4 Specifications ------------------------------------
5 Location of Controls and Components--
5.1. Remote Control Key Button Operation
5.2. Main Unit Key Button Operation
6 Service Mode -------------------------------
6.1. Cold-Start ----------------------------------
6.2. Sales Demonstration Lock Function
6.3. Doctor Mode Table ------
6.4. Self-Diagnostic Mode --
6.5. Self-Diagnostic Error Code Table -
7 Troubleshooting Guide ---------
7.1. No Power or No Display-
7.2. Bluetooth® Pairing Failure--

© Panasonic Corporation 2016. All rights reserved.
Unauthorized copying and distribution is a violation
of law.

Page 2

7.3. No Key Function --------------
7.4. No Remote Control Function-
7.5. No NFC -------------------------
7.6. USB Device Cannot Detect
7.7. No Output Sound--

7.8. Check Point ---------

8 Disassembly and Assembly Instructions-
8.1. Type of Screws -----------------------------
8.2. Disassembly Flow Chart ---------------------
8.3. Main Components and P.C.B. Locations
8.4. Disassembly of Top Cabinet -
8.5. Disassembly of Front Panel Uni
8.6. Disassembly of Panel P.C.B.----
8.7. Disassembly NFC P.C.B.---
8.8. Disassembly of USB P.C.B.
8.9. Disassembly of Mic P.C.B.»

8.10. Disassembly of SMPS P.C.B.
8.11. Disassembly of Main P.C.B. ----------
8.12. Disassembly of CD Mechanism Unit --
8.13. Disassembly of CD Interface P.C.B.

9 Service Position ---------------------
9.1. Checking of Panel P.C.B. --
9.2. Checking of SMPS P.C.B
9.3. Checking of Main P.C.B.-

10 Block Diagram ---------
10.1. System Control -
10.2. Audio -----------
10.3. Power Supply

11 Wiring Connection Diagram--

12 Schematic Diagram --------------
12.1. Schematic Diagram Notes-
12.2. Main (Damp) Circuit (1/2) --
12.3. Main (Damp) Circuit (2/2) --
12.4. Main (Fan LED) Circuit --------
12.5. Main (CD Motor Driver) Circu
12.6. Main (VREG Fan) Circuit (1/2)----
12.7. Main (VREG Fan) Circuit (2/2)----

(
(
(
(

12.8. Main Tuner AUX) Circuit --
12.9. Main IO Expansion) Circuit--
12.10. Main MICON) Circuit (1/2)
12.11. Main MICON) Circuit (2/2)
12.12. Panel Circuit (1/3) ------------
12.13. Panel Circuit (2/3)-
12.14. Panel Circuit (3/3)-
12.15. Mic, USB and CD Interface Circuit -
12.16. SMPS Circuit (1/2) ----------------------
12.17. SMPS Circuit (2/2)
13 Printed Circuit Board
13.1. Main P.C.B. (Side A)---
13.2. Main P.C.B. (Side B)---
13.3. Panel, Mic and USB P.C.B.
13.4. SMPS and CD Interface P.C.B.

14 Voltage and Waveform Measurement
14.1. Voltage Measurement ------------------------

15 Exploded View and Replacement Parts List
15.1. Cabinet Parts Location 1
15.2. Cabinet Parts Location 2---
15.3. Cabinet Parts Location 3
15.4. Packaging -------------------
15.5. Mechanical Replacement Part List -
15.6. Electrical Replacement Part List
