SA-VK7BOGC / SA-VK7BOGCS / SA-VKTGOGCT / SA-VKTBOGS

MPEG4 (.asf)
FAT12, FAT16, FAT32
500 mA (Max)

OUSB device file system
.USB port power
I CASSETTE DECK SECTION

WW 1 way, Auto Reverse
.Track system 4-Track, 2 Channel
Heads

.Record/Playback Solid permalloy head
OErasure Double gap ferrite head
Motor DC servo motor

AC bias 100 kHz
AC erase 100 kHz
4.8 cm/s

Recording system
Erasing system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
35 Hz to 14 kHz
50 dB (A weighted)
0.18% (WRMS)

.Normal

SIN ratio

Wow and flutter

Fast Iorward and rewind time
Approx. 120 seconds with C-60 cassette tape

I VIDEO SECTION

Video system PAL625/50, PAL525/60, NTSC

Composite video output

.Output level 1 Vp-p (75 0)

.Terminal Pin jack (1 system)

Component video output

[NTSC: 480p/430i, PAL: 576p/576i]

.Y output level 1 Vp-p (75 Q)
OPE output level 0.7 Vp-p (75 (2)
OPR output level 0.7 Vp-p (75 (2)

.Terminal

Pin jack (Y: green, PB: blue, PR: red) (1 system)
I Disc SECTION
Disc played [8 cm or 12 cm]
(1) DVD (DVD-Video, DivX57 )
(2) DVD-RAM (DVD-VFt, JPEG7, MP327, MPEG45"'7, DiVX
#7)
(3) DVD-R (DVD-Video, DVD-VR, JPEGM'W MP3~"7, MPEG45"'7,
DiVX7)
(4) DVD-R DL (DVD-Video, DVD-VFt)
(5) DVD-RW (DVD-Video, DVD-VR, JPEG 7, MP3"'7, MPEG4 5~
#71 DIVX S, #7)

(e) +R/+RW (Video)

(7) +R DL (Video)

(8) CD,CD-R/RW [CD-DA, Video CD, svco" , MP37, WMA'W",
JPEGM'W, MPEG457, DiVXH', HighMAT Level 2 (Audio and
Image)]

1 Conforming to IE062107

2 MPEG-1 Layer 3, MPEG-2 Layer 3

3 Windows Media Audio Ver.9.0 L3

Not compatible with Multiple Bit Rate (MBFt)

Exit Ver 2.1 JPEG Baseline files

Picture resolution: between 160 x 120 and 6144 x 4096 pixels

(Sub sampling is 4:0:0, 4:2:0, 4:22 or 4:424). Extremely long and
narrow pictures may not be displayed.

5 MPEG4 data recorded with the Panasonic SD multi cameras or
DVD video recorders.

Conforming to SD VIDEO specifications (ASF standard) / MPEG4
(Simple Profile) video system/ (3.726 audio system.

5 Plays all versions of DIVX® Video (including DIVX®6) with standard
playback of DIVX® media files. Certified to the DivX Stereo System
Profile.

7 The total combined maximum number 01 recognizable audio,
picture and Video contents and groups: 4000 audio, picture and Video
contents and 400 groups.

Pick up

Wavelength

.CD 785 rim
.DVD 662 nm
Laser power

.CD CLASS 1M
.DVD CLASS 1

Audio outpUt (Disc)
.Number of channels (FL, FFt, C, SL, SR, SW) 5.1 ch
Audio performance (measurement at: Ftec out terminal)

OFrequency response (CD-Audio) 4 Hz to 20 kHz

I GENERAL

Power supply

.GC area: AC 220 to 240 V, 50/60 Hz

.GCS/GCT/GS areas: AC 110 to 127V/220 to 240 V,
50/60 Hz

Power consumption 290 W

Power consumption in standby mode
0.9 W (approximate)
250 x 330 x 334.6 mm
5.5 kg
+5°C to +35°C
5% to 90% RH (no condensation)

Dimensions (W x H x D)
Mass
Operating temperature range
Operating humidity range
Notes:
1.Specifications are subject to change without notice.
Mass and dimensions are approximate.

2.Total harmonic distortion is measured by the digital spectrum
analyzer.

I SYSTEM
