Page 1
http://schema99.host.sk/© 2000 Matsushita Electronics (S) Pte. Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law. @ TOP NEXT Sampling frequency 44.1 kHz Decoding 16 bit linear Beam source/wave length Semiconductor laser/ 780 nm Number of channels 2 channels Stereo S/N ratio SP OUT 82 dB (JIS A) WOW and flutter Below measurable limit Digital filter 8 fs D/A converter MASH (1 bit DAC) General Power supply (For GN) AC 230 - 240 V, 50 Hz (For GCS) AC 110 - 120 V/ 220-240 V, 50/60 Hz Power consumption 50 W Standby (For GN) 0.5 W (For GCS) 0.7 W Dimensions (W x H x D) 190 x 149 x 297 mm Weight Approx 3.7 kg Notes: 1.Specifications are subject to change without notices. Weight and dimensions are approximate. 2.Total harmonic distortion is measured by the digital spectrum analyzer. System SC-PM03 (GCS) Music Center: SA-PM03 (GCS) Speaker: SB-PM03 (E) SC-PM03 (GN) Music Center: SA-PM03 (GN) Speaker: SB-PM03 (E)
Page 2
http://schema99.host.sk/7 Self-Diagnostic Display Function TOP PREVIOUS NEXT This unit is equipped with a self diagnostic display function which, if a problem occurs, it will display an error code corresponding to the problem. Use this function when performing maintenance on the unit. 7.1 How to enter the Self-Diagnostic Display Function mode. 7.2 Interpretation of Error Codes. 7.2.1 Abnormality Detection for CD Block 7.2.2 Detailed specification for F75 7.2.3 Abnormality Detection for Power Supply @ TOP PREVIOUS NEXT
