ORDER NO.MD060724ZCE

Service Manual

M [WEE RAM HDI11I

AUDIO/VIBE?) p i. u a n

erwote
Lul moi
[mi wrnei

SUBSUE 59:39:45 sizwgss

SB +3995

Specifications

[General

Power Source: AC 230V, 50Hz
Power consumption: 120 W
Dimensions (WXHXD): 430><60><354 mm
Mass: 3.35kg

[Amplifier section
RMS Output Power: Dolby Digital Mode
[Total RMS Dolby Digital

mode Power: 1000 W
At 1kHz and total harmonic of 10%
[Front: 125 W/ Channel (30)
[Center: 250 W/ Channel (60)
lSurround: 65 W/ Channel (40)
At 100Hz and total harmonic of 10%
[Subwoofen 250 W/ Channel (60)

DIN Output Power: Dolby Digital Mode:
[Total DIN Dolby Digital mode Power:

470 W

At 1kHz and total harmonic of 1%
[Front: 80 W/ Channel (30)
[Center: 75 W/ Channel (69)

Panasonic®

DVD Home Theater Sound System

SA-HT995EE
Colour
(8). .Silver Type

lSurround: 80 W/ Channel (30)
At 100Hz and total harmonic of 1%
[Subwooterz 75 W/ Channel (69)
[Preset Memory: FM 15 stations

AM/MW 15 stations

[Frequency Modulation (FM)

Frequency Range: 87.50»108.00MHz
(50kHz step)

Sensitivity: 2.5pV (IHF)

SIN 26dB 2.2pV

Antenna Terminals: 759 (unbalanced)

[Amplitude Modulation (AM/MW)

Frequency Range:
AM Sensitivity SIN 20dB at
999kHz: 560uV/m

522-1629kHz (9kHZ step)

[Digital audio input:

Optical digital input: Optical terminal (1 system)

Sampling frequency: 32kHz, 44.1kHz, 48kHz

[Phone Jack:

Terminal: Stereo 3.5 mm jack

[Mic Jack:
