Page 2

SA-HTIZDP l SA-HT'IZDPC

(4) DVD-R (DVD-Video compatible)
5) CD-Audio (CD-DA)

6) Video CD

7) SVCD (Conforming to IE062107)

8) CD»R/CD-RW (CD-DA, Video-CD, SVCD, MP3, WMA, JPEG
formatted discs)

(9) MP3/WMA
[Maximum number of recognizable audio and picture contents

(
(
(
(

S-video output:
Y output level:
C output level:
Terminal

1 Vp»p (75 £2)
NTSC; 0.286 Vp-p (75 n)
8 terminal (1 system)

Component video output (480PI480l):

Y output level:
PB output level:
PR output level:

1 Vp-p (75 o)
0.7 Vp-p (75 o)
0.7 Vp-p (75 o)

and groups:

4000 audio and picture
contents and 400 groups

[Compatible compression rate:
MP3: between 32 kbps and 320 kbps
WMA: between 48 kbps and 320 kbps

(10) JPEG

lExif Ver 2.1 JPEG Baseline files
[Picture resolution: between 320 x 240 and 6144 x 4096
pixels (sub sampling is 4:2:2 or 4:220)

(11) HighMAT Level 2 (Audio and Image)

Pick up:
Source of light beam:
Wavelength:
1CD:
lDVD:
Audio output (DlSC):
Number of channels:

Audio performance:
Frequency response:
DVD (linear audio):

DVD-Audio:

CD-Audio:

SIN ratio:
CD-Audio:

Dynamic range:
DVD (linear audio):
CD-Audio:

Total harmonic distortion:
CD-Audio:

lVideo section

Video system:
Signal system:

Composite video output:
Output level:
Terminal:

Semiconductor Laser

785nm
662nm

5.1 ch (FL, FR, C, SL, SR,

SW)

4 Hz-22 kHz (48 kHz sampling)
4 Hz-44 kHz (96 kHz sampling)

4 HZ-88 kHz (192 kHz
sampling)
4 HZ-20 kHz

95 dB

95 dB
93 dB

0.005 "/0

NTSC

1 Vp-p (75 9)
Pin jack (1 system)

Terminal: Pin jack (Y: green, PB : blue,
PR : red) (1 system)
Power consumption in standby mode:
approx 0.4W
Note:
1. Specifications are subject to change without notice.
Mass and dimensions are approximate.

2. Total harmonic distortion is measured by the digital spectrum
analyzer.

Solder:

This model uses lead free solder (PbF).

system SC-HT720
Main unit SA-HT720
Front speakers SB-FS720
Center speaker SB-PC720
Surround speakers SB-FSSZO
Active subwoofer SB-WA720

MPEG Layer-3 audio decoding technology licensed from Fraunhofer
IIS and Thomson multimedia.

Windows Media. and the Windows logo are

trademarks, or registered trademarks of .
Microsoft Corporation in the United States and/ .
or other countries. . _
WMA is a compression format developed by new ,m
Microsoft Corporation. It achieves the same mm

sound quality as MP3 with a file size that is Medla
smaller than that ol MP3.

HighMAT and the HighMAT logo are either
trademarks or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.

l Built-in decoders

You can play discs with these symbols. DU
0 I G I T A L

DIGITAL

SURROUND

AWARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
