Panasonic sa ak 44 service manual
This is the 27 pages manual for panasonic sa ak 44 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic sa ak 44 service manual (Ocr-read)
Page 1
Contents page Mechanism bottom view and part names ................................................... 1 Mechanism top view and part names ......................................................... 2 Drive system ............................................................................................... 3 Operation of the main gear from the stop mode to the play mode ............. 4 Switching between forward and reverse during the play mode .................. 5 Operation of the forward/reverse lever and forward/reverse rod ................. 6 Operation of the main gear and forward/reverse lever ................................ 6 Head switching operation/Pinch roller switching operation ......................... 7 Operational relationship between head substrate and main gear .............. 8 Reel base mode switching operation (stop, forward-play, and reverse-play modes) ..................................... 9 Relationship between take-up arm, main gear, and reel base gears (during play mode) .......................................... 10 Reel base switching mode (fast-forward, rewind, and stop modes) ......... 11 Eject operation (stop mode) ..................................................................... 12 Eject operation (cassette cover open) ...................................................... 13 Block diagram ........................................................................................... 14 Timing char t ............................................................................................. 15 Fast Forward (FF) and Rewind (REW) ..................................................... 16 Assembly of parts at top of mechanism ........................................... 17 ~ 19 Assembly of parts at bottom of mechanism ..................................... 20 ~ 23
Page 2
- 1 - Mechanism bottom view and part names Forward/reverse lever1 2 3 4 Eject lever Trigger lever Trigger lever spring Forward/reverse lever spring 5 Fast-forward relay gear6 Plunger (solenoid)7 Main gear8 Take-up arm9 Take-up belt 10 Forward flywheel 11 Take-up belt 10 Reverse flywheel 14 Thrust spring 12 Take-up lever 13 Switch substrate Reel base gear A Reel base gear B Chassis 1 2 3 4 5 6 7 8 9 10 11 13 14
