Panasonic rx d25
This is the 8 pages manual for panasonic rx d25.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic rx d25 (Ocr-read)
Page 1
RQT67442 These speakers do not have magnetic shielding. Do not place them near televisions, personal computers or other devices easily influenced by magnetism. FM mode select/CD stop/program clear button ( FM MODE/CLEAR) RX-D25 only RX-D25 RX-D21 TUNER H.E.S. XBS CD Main unit: /CLEAR/ –//+ / RX-D25 only Remote control RX-D25 only : The functions of the buttons without descriptions are the same as on the main unit. Battery installation Insert the batteries (not included) observing the correct polarities (e,d). Operation notes -Do not place obstacles between the remote control signal sensor and the remote control unit. -Do not expose the remote control signal sensor to direct sunlight or to the bright light of fluorescent light. -Take care to keep the remote control signal sensor and end of the remote control unit free from dust. To prevent damage -Never place heavy items on it. -Do not disassemble or reconstruct it. -Do not spill water or other liquids into it. Correct method of use Concerning the remote control Transmission window About 7 meters in front of the signal sensor Remote control signal sensor 1 2 R6, AA, UM-3 RX-D25 only Controls P1-211/18/02, 4:05 PM 2
Page 2
RQT67443 1 Switch [ ] to TUNER. (Unit comes on.) aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 2 Press [BAND] to select FM or AM. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 3 (Omit this step if using the remote control) If is on the display, press [TUNE MODE] to clear it off. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 4 Press [–/g] or [f/+] to tune to the desired station. The frequency changes one step each time a button is pressed. Automatic tuning Keep [–/ g] or [f/+] depressed and release when the frequency display starts to change. A station with good reception is automati- cally selected and the process stops. To stop automatic tuning, press [–/ g] or [f/+] again. Note Automatic tuning may stop on a frequency where there is no station if there is interference. Press [–/ g] and [f/+] to tune if this occurs. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 5 Adjust the volume. To use auto scan You can search for a station by listening to all tuned-in stations for 8 seconds each. Preparation: Switch [ ] to TUNER. 1. Press [BAND] to select FM or AM. 2. Press [AUTO SCAN]. Auto scan starts. 3. Press [AUTO SCAN] when you find the desired station. Auto scan ends when it reaches the original frequency again. To stop during the process, press [AUTO SCAN]. To improve receptionFM: Extend the whip antenna and adjust its direction. AM: Adjust facing of the unit. If noise is excessive in the FM stereo mode Press [FM MODE]. ( lights up.) Sound will be produced in monaural, but this also reduces noise. Press the button again to cancel. ( goes out.)Preset the stations (twelve FM and twelve AM) to make tuning simpler. Preparation:Tune to the desired station. (Do steps 1–4 on the left.) aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 1 Press [MEMORY]. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 2 While and the frequency are flashing Press [MEMORY]. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 3 While and the preset channel are flashing Press [–/g] or [f/+] to select the desired channel. (Remote control: [ 4 44 4 4] or [ 3 33 3 3]) aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 4 Press [MEMORY]. (This completes presetting.) aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa Repeat the above to preset other stations. Note If goes off during presetting, return to step 1. 1 11 1 1 Press [BAND] to select FM or AM. aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 2 (Omit this step if using the remote control)Press [TUNE MODE] to display . aaaaaaaaaaaaaaaaaaaaaaaaaaaaaaaa 3 Press [–/ g] or [f/+] to select the desired channel (1–12). (Remote control: [ 4 44 4 4] or [ 3 33 3 3]) To use preset scan You can search for a station by listening to all preset channels for 8 seconds each. 1. Do steps 1 to 2 above. For remote control, replace [– / g] or [f/+] described below with [ 4 44 4 4] or [ 3 33 3 3]. 2. Press and hold [–/ g] or [f/+] until PS appears on the display. 3. Press [–/ g] or [f/+] when you find the desired channel. Preset scan ends after searching through each preset channel once. To stop during the process, press [–/ g] or [f/+]. Normal tuning Preset tuning The Radio To listen to preset channels How to preset Indicates auto scan Indicates preset scan lights when an FM stereo broadcast is being received. Preset channel Preset channel 3 2 15 4 1 2 3 124 3 P3-411/20/02, 11:25 AM 3
