CONTENTS

ITEM

0 Safety Precautions...,.......
- Insulation Resistance Test
0 Location of Controls and Components
- Cleaning of Lens.

- Handling Precautions for Optical Pickup
- Disassembly Instructions...
. introduction to New Functions
0 Block Diagrurn (Main & Tuner Section)...
- Schematic Diagram (Main Circuit Section)
- Electrical Parts List (Main & Tuner Section)
- Resistors and Capacitors (Main & Tuner Section).
' Circuit Boards (Main/Tuner Circuit Board)
- Schematic Diagram (CD Player Section).
- Resistors and Capacitors (CD Player Section).
- Circuit Board (CD Player Section) ............... .
- internal Connections of LCD ............................................... 43

PAGE

SAFETY PRECAUTIONS (For U.S.A.)

Before servicing, unplug the power cord to prevent an electric shock.

When replacing parts, use only manufacturer's recommended components for safety. ,
Check the condition of the power cord. Replace if wear or damage is eVident. 3
After servicing, be sure to restore the lead dress, insulation barriers, insulation papers,

95".?

sheilds, etc

5. Before returning the servrced equipment to the customer, be sure to make the following part
insulation resistance test to prevent the customer from being exposed to a shock hazard.

ITEM PAGE
- Block Diagram (CD Player Section) .................................... 44
- Terminal Function of LSI... . 50

.. 55
.. 57
. 75

- Troubleshooting (CD Player Section)
0 Measurements and Adjustments (CD Player Section)
- Points to check Following Repair............,..................
0 Measurements and Adjustments

(Radio and Tape Section) ..... 76
- Exploded Views (CD Player Section) .................................. 79
- Disassembly Procedures for The Major

Mechanical Parts......
- Disassembly Mechanism Circuit Board
- Mechanism Parts Location (Tape Deck Section)
- Cabinet Parts Location .......................................
- RX-CD70 Importance Parts........
- Accessary and Packing Materials

Antenna
terminal \ I

Exposed
meiai

Ohmmeter
Fig. 1
ReSistance : 3M975 2M3)

INSULATION RESISTANCE TEST (For U.S.A.)

1. Unplug the power cord and short the two prongs of the plug With a jumper wire.

2. Turn on the power switch.

3, Measure the resistance value with ohmmeter between the jumpered AC plug and each
exposed metal cabinet part, such as screwheads, antenna, control shafts, handle
brackets, etc. Equipment with antenna terminals should read between 3M9 and 5.2 M9 to

antenna

all exposed parts. (Fig. 1) Equipment without
approximately infinity to all exposed parts. (Fig. 2)

* Note: Some exposed parts may be isolated from the ChasSlS by design. These wtll read

infinity.

4. If the measurement is outside the specified limits, there is a possibility of a shock hazard,
The equipment should be repaired and rechecked before it is returned to the customer.

Exposed .7 ,,
metal
part

terminals should read

Ohmmeier
Fig. 2

Resistance: Approx co

CAUTION:
THIS PRODUCT UTILIZES A LASER.

USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
