Specification
nGeneraI

Power Requirement:
Battery;

Rechargeable Battery;

Power output:

Output jack:
Dimensions(WxHxD):
Weight:

nCharger

Input;

For the United Kingdom;
For Continenntal Europe;
Output;

Wow & Flutter;
nCassette Player

DC 1.5V (one R6/LR6,"AA"
battery)

DC 1.2V (included rechargeable
battery)

1.5mW+1.5mW (RMS...max)
Headphone;80§2,M3 jack

80.7 x 110 x 23.2 mm

1569 (With rechargeable battery)

AC 220 ~ 240V,50Hz,4W
AC 220 ~ 230V;50HZ,4W
DC 1.2V, 350 mA
WRMS 0.28%

TD0502008C2

ce Manual

Mini Cassette

RQ-SX59EG
RQ-SX59EB

Stereo Cassette Player

Colour
(S) ............ Silver Type

AR21 Mechanism Series

Track system: 4 track, 2 channe|,stereo
40 ~18,000HZ (-6 dB)

About 3.5 hours

Frequency Range (Normal)
Recharging time:

Motor: Electrical governor motor
Tape Speed: 4.8 cm/s
Playing time:

(When used in hold mode, at 25°C and on flat stable surface)

Battery type
Rechargeable battery 1
Alkaline battery

Rechargeable battery 1

Alkaline battery

Tape playback
About 18.5 hours
About 47.5 hours

About 66 hours

1 When the included rechargeable battery is fully recharged

Note:

(requires 3.5 hours )

Specifications are subject to change without notice.

Mass and dimensions are approximate.

The play time may be less depending on the operating conditions.

AWARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death

Panasonic

© 2005 Matsushita Electric TAIWAN Industrial Co.,
Ltd. All rights reserved. Unauthorized copying and
distribution is a violation of law.

Page 2

RQ-SXSSEG I RQ-SXSSEB

CONTENTS

1 Accessories ----------

2 Location of Controls

3 Service Mode .......................................................................... 4
3.1. Unit and Stereo Earphones Test ..................................... 4
3.2. Remote Controller Test -------------------------------------------------- 4

4 Operation Checks and Component Replacement Procedures5

4.1. Removal of the rear cabinet ass I] ................................. 5
4.2. Removal of the cassette lid ............................................ 5
4.3. Removal of the link angle and link unit ............................ 5
4.4. Removal of the main P.C.B_ ........................................... 5

4.5. Remov the battery terminal (-) and (+) -6
4.6. Checking for the main P.C.B. --------- -6
4.7. Removal of the mechanism ass D and middle cabinet ----7

4.8. Remove of the head block and pinch rollers .................... 7
4.9. Removal of the open knob ............................................. 7
4.10. Removal of the lock cam and lock sprin

4.11. Removal of the open spring and sheet-
4.12. Notice for assembling the mechanism ............................. 3
4.13. Notice for assembling the main P.C.B. ............................ 8

1 Accessories

- Stereo earphones
(FFEV330P-HT) ............................................................. 1pc.

- Remote Control
(RFEV036P-HS) ............................................................. 1pc.

- Battery Charger Stand

(RFEB116E-1U) . .[EG].
- Battery Charger Stand
(RFEB115B-1U) .............................................................. [EB].

- Stand Charger Holder
(RKQT0041-A) ................................................................ 1 pc.

4.14. Notice for assembling the cassette lid -----------

4.15. Notice for assembling the rear cabinet ass D

5 Check Point of Signal ............................................................. g
6 Block Diagram ........................................................................ 9
7 Schematic Diagram Notes ...................................................... 9
8 Schematic Diagram ------------

9 Printed Circuit Board Diagram

10 Type Illustration of ICs, Transistors and Diodes .................. 15
11 Measurements and Adjustments .......................................... 15
11.1. Adjustment Instructions ................................................ 15

11.2. Adjustment Points
12 Terminal Function Of IC D

13 Supply of Rechargeable Battery as Replacement Parts ------- 16
14 Caution in Use of Rechargeable Battery ............................... 16
15 Mechanism Parts Location ................................................... 17

16 Cabinet Parts Location-

17 Packaging .................
18 Replacement Parts List _________________________________________________________ 19

- Battery Ass'y
(HHF-AZOQEMST)...

- Battery Case

(RFCTOOOS-H) .. . 1pc.

- Battery Case
(RFATOOOG-H) ................................................................ 1pc.
