Page 2

1 Put the main and sub units either side of the bed.

2 (D Open the back panel of the sub unit and take out enough cord for
the distance between the units.

® Close the panel, ensuring the cord lite Into the slit at the bottom
at the compartment.

(D Back oi sub unit

/

(_.
Connect the cables to the terminals of the same
color, so ® and e are correct.

Never allow the exposed wires to contact each other Connect the AM loop antenna.
when connected. Incorrect connection can damage Stand the antenna up so it clicks into place.
the unit.

The green and blue cables carry commands. The
red and black cables carry sound

Back of main unit

6 Connect the AC power supply cord.
Connect this cord after all other cables and
cords are connected.

When disconnecting
Pull firmly.

Insert the memory backup battery.
This saves the clock, timer, and radio-pre-
set settings it power is interrupted,

@«w

p
Antenna
lead -
The included AC power supply cord is lor use (D (a
with this unit only. Do not use it with other .)
e ui ment.
q p :1 6F22/6LH61,
7 Change the speaker channel. MAIN UNIT -J 006i? battery
R: It the main unit is to the right when you J (not Included)
are lying down. |_ ch [E R ch
L: If the main unit is to the left when you are .1: basally lasts about a year (one month
lying down. H W' ou power).

if you set the units up away from the bed, set [MAIN UNlT] to [L] if
k you put the main unit on the right, and vice versa. )

sing headphones (not 'ncluded)

Plug type: 3.5 mm (/a in.) stereo

o The alarms lunction when you connect headphones, and the buzzer
sounds through the speakers, even it you set ALARM 1 (CD or radio).
0 Avoid listening for long periods of time to prevent hearing damage,

Back of
main unit
