Page 2

Power sources

AC power supply cord

CD, Radio

Connect the AC power supply cord to a household AC outlet.

Back of the unit

Plug in tlrmly. Display
AC power supply cord C)

These speakers do not have magnetic shielding. Do not place them near
televisions, personal computers or other devices easily influenced by mag-
netism.

Memory hock-up battery (not included)

This battery saves the clock, timer and radio preset settings if there is a
power interruption.

Bottom ol the unit 1 (not included)

(No battery cover is used.)

Antenna lead
(lor U.S.A)

Antenna lead
(lor Canada)

Replacing the battery

IThe battery lasts about a year.
The battery lasts about a month if the unit is disconnected from the
household AC outlet.

oProtect the memory by connecting the AC power cord belore changing
the battery.

OAIign the poles (e and 6) properly when inserting the battery.

000 not heat or disassemble batteries. Do not allow them to contact flame
or water.

ofiemove the battery ii the unit is not to be used for a long time.

IDo not use the battery it the covering has been peeled off.

Mishandllng of batteries can cause electrolyte leakage which can damage
items the fluid contacts and may cause a tire.

It electrolyte leaks lrorn the batteries, consult your dealer.

Wash thoroughly with water it electrolyte comes in contact with any part of
your body.

CD lid open button

(2 OPEN)

CD play mode,
FM mode button
(MODE)

Volume control

(VOLUME)

Skip. search, tuning but-
tons ( >>l>>l, + and
l«/<<,-)

XBS button

Preset channel buttons
(1' 2. 3. 4. 5 )

Stop button ( OFF, I)
CD play, pause button
(CD. HI)

Radio on, Band
select button
(RADIO, FM/AM)

Alarm, Sleep timer and Basic operations

CD/Fladio alarm setting but-
tons

Display button
(DISPLAY)
Back light button

(BACKL'GHT) Buzzer alarm setting buttons

Time adjust buttons

Doze button
(DOZE)

Stop button
(OFF, I)

Time set button
(TIME sET)

Sleep timer button
(SLEEP)

Display
