ORDER NO.DSD0711017CE
B35

Service Manual

BIu-ray Disc Player
Mode.NO.DMP-BD30PP

DMP-BD30PL

Vol. 1
Colour
(K) ....................... Black Type

other countries.

Java and all Java-based trademarks and logos are trademarks or registered trademarks at Sun Microsystems, Inc. in the United States and

Manufactured under license Irom Dolby Laboratories Dolby and the double-D symbol are trademarks of Dolby Laboratories.

DTS is a registered trademark of DTS, Inc. and DTS-HD Advanced Digital Out" is a trademark of DTS, Inc.

US. Patent Nos. 6,836.549: 6.381.747: 7,050,698; 6,516,132; and 5,583,936.

This product incorporates copyright protection technology that is protected by US. patents and other intellectual property rights. Use of this
copyright protection technology must be authorized by Macrovision, and is intended tor home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

HDMI. the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.

LLC. See http://wwwmpeglacom.

This product is licensed under the AVG patent portfolio license and VC-1 patent portfolio license tor the personal and non-commercial use of a
consumer to (i) encode video in compliance with the AVG Standard and VC-t Standard (AVCNC-t Video") and/or (ii) decode AVC/VC-1 Video
that was encoded by a consumer engaged in a personal and non-commercial activity and/or was obtained from a video provider licensed to
provide AVCNC~1 Video. No license is granted or shall be Implied for any other use. Additional inlormation may be obtained from MPEG LA.

HDAVl Controlm is a trademark of Matsushita Electric Industrial Co., Ltd.

EZ Syncw is a trademark of Matsushita Electric Industrial 00.. Ltd.

AVCHD and the "AVCHD" logo are trademarks of Matsushita Electric Industrial Co.. Ltd. and Sony Corporation.

SDHC Logo is a trademark.

Portions of this product are protected under copyright law and are provided under license by ARIS/SOLANA/4C.

A WARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

TABLE OF CONTENTS

1 Safety Precaution ---------
1.1. General guidelines -
1.2. Caution for fuse replacement-

2 Warning ---------------------------------
2.1. Prevention of Electrostatic Discharge (ESD)

to Electrostatic Sensitive (ES) Devices
2.2. Precaution of Laser Diode ------------
2.3. Service caution based on legal restrictions

3 Service Navigation ---------------------------------------
3.1. Service Information --------------------------------------- 7

4 Specifications --------------------------------

5 Location of Controls and Components

Panasonic?

PAGE

6 Operation Instructions ---------------------------------------- 10
6.1. Taking out the Disc from BD/DVD Drive Unit
when the Disc cannot be ejected by OPEN/

CLOSE button -------------------------------------------- 10

7 Service Mode ----------------------------------------------------- 11

7.1. Self-Diagnosis and Special Mode Setting -

3 Service Fixture & Tools ----------------------------

9 Disassembly and Assembly Instructions
9.1. Disassembly Flow Chart ---------------

9.2. P.C.B. Positions ------------------------------------------ 20

© 2007 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and distribu-
tion is a violation of law.
