Number of Pixels 336,960 pixels

(234 vertical x 480 horizontal x 3)
Valid Pixel Ratio Over 99.99%
Display Method Transparent color filter format
Drive Method TFT (Thin Film Transistor)

active matrix format
Light Source Internal light

(Built-in small fluorescent lamp)
Dimensions (W x H x D) 178 x 50 x 165 mm
Weight " 2.4 kg
* Specifications and the design are subject to possible modification without notice due to improvements.
Dimensions and Weight shown are approximate.

0 Above specifications comply with EIA standards.

© 2007 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.

A WARNING

This sorVioc intormation is dcstgncd tor experienced repair technicians only and is not dcsrgnod tor use by the general public.

It does not contain warnings or cautions to advrse non-technical indivrduals oi potential dangers In attempting to sorvrm a product.
Products powered by electricity should be servroed or repaired only by experienced protessional technicians. Any attempt to service
or repair the product or produc15 dealt wrth in this service intermation by anyone else could result in senous iniury or death

Panasonic
IMPORTANT SAFETY NOTICE

There are speCial components used in this equipment which are important tor salety. These parts are marked by LA in the Schemalic
Diagrams. Circuit Board Diagrams. Exploded Views and Replacement Parts Ust It is essential that these mtical pans should be replaced
Wl|h manufacturer's specnlied parts to prevent shock. lire or other hazards Do not modify the original design without permissron ol

man U'BCYU rer
