Panasonic cq vd 7001 h service manual

Page 2

CO-VD7001 H

(Built-in small fluorescent lamp)

178 x 50 x 165 mm
2.4 kg

Dimensions" (W x H x D)
Weight"

" Specifications and the design are subject to possible modification
without notice due to improvements.

Dimensions and Weight shown are approximate.

0 Above specifications comply with EIA Standards.

AWARNING

This service information is designed for experienced repair technicians only and is not designed for use by the general public

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians Any attempt to service
or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.

IMPORTANT SAFETY NOTICE

There are special components used in this equipment which are important for safety, These parts are marked by A in the Schematic
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer's specified parts to prevent shock, fire or other hazards Do not modify the original design without permission of

manufacturer,

CONTENTS

Page
1 ABOUT LEAD FREE soLDER (PbF) --------------------------------------- 3
2 FEATURES ------------------------------------------------------------------------------ 3
3 REPLACING THE FUSE ---------------------------------------------------------- 3
4 MAINTENANCE ....................................................................... 3

5 LASER PRoDucTs .................
e DISASSEMBLY INSTRUCTIONS- .4
7 WIRING CONNECTION ............................................................ 5
8 TERMINALS DESCRIPTION ..................................................... 7

Page
9 PACKAGE AND Ic BLOCK DIARAM -------------------------------------- 11
1o REPLACEMENT PARTs LIST ------------------------------------------------ 20
11 EXPLODED VIEw (Unit) -------------------------------------------------------- 33
12 DVD PLAYER PARTS LIST ---------------------------------------------------- 34
13 EXPLODED VIEW (DVD Deck) -38

14 WIRING DIAGRAM ................. 39
15 SCHEMATIc DIAGRAM ......................................................... 4-,
16 BLOCK DIAGRAM ................................................................. 55
