Panasonic bbd databook

Page 2

The devrce specrilcauons are subject to change Without prior notice
While every precaution has been taken in the preparatlon or this data
sheet the publisher assumes no lesponslblllty for parent IIabIIlIV With
respect to the use of the information Contalned helelri

BBD SERIES

Bucket Brigade Devices

Panasonic holds a leadership position in the
area of BBDs foraudio signal delays. Sincethe
first BBD (type MN3001) was developed, vari-
ous new types have been introduced to meet
the expanding market requirement. Now the
product range has expanded to twelve types,
ranging from 64-stage to the longest 4096-
stage BBD.

This edition of ourBBD Series catalog con-
tains detailed information on the twelve types
of products in this series already in production.
It further information is required for your BBD
application, please feel free to contact our sales
offices, representatives or distributors. We al-
ways wish to offer you better service to satisfy
your quality and performance requirements.

CONTENTS
INTRODUCTION ........................... 1
TYPICAL APPLICATIONS ................... 1
CLOCK FREQUENCY and SIGNAL
DELAY TIME ............................... 1
SELECTION GUIDE by STAGES ............ 1
BBD QUICK REFERENCE TABLE ........... 2
SPECIFICATIONS and CHARACTERISTICS

MN3001, MN3002 .......................... 3
MN3003 ................... .. ........... 9

MN3004 ................................ 13
MN3005 ................................ 18
MN3006 ................................ 23
MM3007 ................................ 28
MN3008 ................................ 32

MN3009 . . . . 36
MN3010 . . 4O
MN301 1 ................................ 44
MN3012 ................................ 50
MN3101 ................................... 56
