Page 1
2 > Before star t> Hookup > Setup > Playback > Par t Names > Advanced Manual Troubleshooting | Appendix What's in the box 1. Main unit 2. Remote controller (RC-911R) ×1, Batteries (AAA/R03) ×2 3. Indoor FM antenna ×1 4. AM loop antenna ×1 5. Speaker setup mi crophone ×1 6. Power cord ×1 Main features This unit is connected between your TV and your AV components. To play, select the source with the input selector. You can connect 7.1c h of speakers to this unit, with 7ch at 180 W (6 ohms, 1 kHz, 0.9%THD) (North American models) / 175 W (6 ohms, 1 kHz, 1%THD) (European, Austral ian and Asian models) per channel plus pre out jack for powered subwoofer. $Conforms to the THX Select2 Plus specification: THX is a series of specifications for the accurate reproduction of movies propounded by the film dir ector George Lucas. This unit is equipped with a variety of THX technology to faithfully reproduce according to the sound design envisaged by the movie producer, including surround modes that take account of factors such as the size and number of speakers, and the differences in environments between home theaters and movie theaters. $Supports playback in Dolby Atmos format which provides 360 e sound placement$The HDMI jack supports 4K vid eo input and output. Jacks IN1 to 3 and OUT MAIN/SUB support HDCP2.2$HDMI CEC functionality: Control features such as linking input switching with the input selector and players conforming to the CEC standard, switching audio output and volu me using the remote controller of a CEC- compliant TV, and automatically s witching this unit to standby when the TV is turned off $HDMI Standby Through: Video and audio signals from AV component s can be transmitted to the TV even if this unit is in standby$ARC: Connection with an ARC-compat ble TV is complete with one HDMI cable$Easy Initial Setup using onscreen guidance and On-Screen Display (OSD) showing operations on the TV$Internet radio and AirPlay via wi red LAN or Wi-Fi (wireless LAN) and network features such as Music Server that enables PC music file play back, USB playback, plus other p layback features such as AM/FM radio and BLUETOOTH ® play $Playback formats supported by Music Server and USB include WAV, FLAC and DSD high-res source$Multi-zone Connection which allows you to play in the main room and listen in a separate room (ZONE 2)$Equipped with RS232 port, IR IN jack, and 12V TRIGGER OUT jack$We plan to provide support for the DTS:X audio format through a firmware update for this unit. Refer to our website for more information. CAUTION: Connect speakers with 6 Ω to 16 Ω impedance. When connecting spe akers to both ZONE 2A and ZONE 2B (North American models) ( P18), both sets of speakers connected in ZONE 2 should have 8 Ω to 16 Ω impedance. The power cord must be connected only after all other cable connections are completed. 0 We will not accept responsibility for damage arising from the c onnection of equipment manufactured by other companies. 1 2 56 34 (For North American, European and Asian models)
Page 2
3 > Before star t> Hookup> Setup > Playback > Par t Names > Advanced Manual Troubleshooting | Appendix Step1: Choose your Speaker Layout 12 Front Speakers 3 Center Speaker 45 Surround Speakers 6 Powered Subwoofer For 5.1-Channel System This is a 5.1-channel system that is the basic surround system. Front speakers output front stereo sound and a center speaker outputs center sound such as dialogs and vocals. Surround speakers create back sound field. Powered subwoofer reproduc es bass sounds and creates rich sound field. The front speakers should be positioned at ear height, while the surround speakers should be positioned just above ear height. Center speaker should be set up facing the listening position. Place the powered subwoofer towards the front. Placing it between the center speaker and a front speaker gives you a natural sound even when playing music. 0 The front speakers, center speaker, and surround speakers are counted as 5 channels, and the powered subwoofer is counted as 0.1 o f a channel, giving us the name 5.1ch system. Î 1: 22 e to 30 e, Î 2: 120e G o To "Hookup" ( P9) Î 1 Î2
