Onkyo TX 8011 Service Manual
This is the 27 pages manual for Onkyo TX 8011 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Onkyo TX 8011 Service Manual (Ocr-read)
Page 1
TX-801 1
Ref. No. 3849
ONKYO SERVICE MANUAL 92°
STEREO RECEIVER
MODEL TX-8011
\-/
RC-33OS
Black model
BMDD 120V AC, 60 Hz
SAFETY-RELATED COMPONENT
WARNING I !
COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ()NKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT ()R RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
ONKYO.
IMAGINATIVE SIGHT & SOUND
