TA-6510

Ref. No. 3510

ONKYO SERVICE MANUAL

CASSETTE TAPE DECK
MODEL TA-6510

l UD 120VAC,60Hz
l UP 230VAc, 501712
l UW 120/220VAC, 50/60Ilz

SAFETY-RELATED COMPONENT WARNING

COMPONENTS IDENTIFIED BY MARK A ON
THE SCHEMATIC DIAGRAM AND IN THE PARTS
LIST ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE THESE COM-
PONENTS WITH ONKYO PARTS WHOSE PARTS
NUMBERS APPEAR AS SHOWN IN THIS MANUAL.

MAKE LEAKAGE-CURRENT 0R RESISTANCE
MEASUREMENTS TO DETERMINE THAT
EXPOSED PARTS ARE ACCEPTABLY IN-
SULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE APPLIANCE TO THE
CUSTOMER.

ONKYO.
MIIIIII BIIMIIIIIIIIIS

24.max

SPECIFICATIONS

Track Formal:
Erasing System:
Tape S peed:
Wow and Flutter:

44:34:16. 2-channels
AC erase
4.8 cut/sec. (1-7/8 i.p.s.)
0mm (WRMS)
0.09 ODIN)
20-18.000Hz (normal)
(30-17,0(X)Hz..+.3dB)
20-19.IX10Hz(hlgh)
(30»18,0(X)Hzi3d3)
20-20.000Hz (metal)
(30-19.IXX)H1 fldB)
GOdB (metal tape, Dolby NR off)
A noise reduction of 10dB above
SkHz and SdB at lkHz is possible
with Dolby 3 NR. A noise reduction
of 20:13 at Sld-Iz is possible with
Dolby (2 NR.
LINE IN: 2
Input sensitivity: 80 mV
Input impédanoe: 50 kohms
LINE OUT: 2
Standard output level: 500 mV
(013)
Optimum load impedance: over
$0 kuhms
Headphone jack:l
Optimum load impedance28 to
200 ohms
DC servo motor: 1
DC motor: 3
Heads: REC/PB: Special Hard Pennalloy x 2
Erase head: Ferrite x l
UK. and Australian models
AC 2A0 V 50 Hz
European models (Except U.l(i)
AC 230 V. SDI-[z
Worldwide models
AC l20 and 220 V. Switchable
50/60 Hz
13 watts
455(W)x120(H)x 310(D)mm
17"];6" x 4 ll." x 123/13"
5.0 kg.(ll.01bsi)

Frequency Response:

S/N Ratio:

Input Jacks:

Output lacks:

Motors:

Power Supply Rating:

Power Consumption:
Dimensions:

Weight:

Specifications and external appearance are subject to change will
out notice because ofprcduct improvements.
