Onkyo SKSHT 750 Service Manual

Page 1

SKS-HT750

Ref. No. 4034

ONKYO SERVICE MANUAL °92°°7

7.1-CH HOME THEATER SPEAKER PACKAGE

Surround Back Speakers (L / R)
"SKB-750"

MODEL SKS-HT750(B)

Center Speaker
"SKC-750C"

Front Speakers (L / R) Surround Speakers (L / R)
"SKF-750F" "SKM-7SOS"
Black model

B MDC 120V AC, 60Hz

SAFETY-RELATED COMPONENT
WARNING! !

COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE

CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.

REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.

MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

ONKYO®

IMAGINATIVE SIGHT SI SOUND

Powered Subwoofer
"SKW-750"

. V
V
