Onkyo MULTIAC 70 P Owners Manual

Page 2

WE THANK YOU FOR CHOOSING OUR AUDIO EQUIPMENT

(FEATURES)

The player is designed and manufactured to meet completely the
requirements of stereo sound reproduction. The 31 cm turntable
is made of die-cast precision-finished aluminum. It is driven by
a special urethane-resin belt. For this reason, it is free from
wow, flutter and motor rumble, and ensures stable rotation for
a long time.

T1e pickup is fitted with an S-pipe-arm, which is of negligible
moment of inertia and resonance-free, and with a high-fidelity
MM-cartridge, which has excellent high note and transient chara-
cteristics. For further precision, the pickup incorporates a lateral
balancer, a pivot suspension system, a convenient stylus-pressure

adjustor, head shell exchanging system and so on-o-With the user
in mind, careful attention has been paid to details.

(SPECIFICATIONS)
Type 2 speed beltdrivc auto-return auto-cut
Turn table 12 t "(31cm)aluminum die-cast
Speeds 33 a, , 45r.p.m.
Motor 4-pole Synchronous Motor
Cartridge Moving magnet type
Stylus Pressure 3.0gr
Stylus Diamond.
Arm Static balanced pipe-arm with lateral balancer
& anti-skating control
Power Supply AC 100V 50/60Hz
l Power Consumption 10W
Dimensions 18 i W><15D X7 2."

. weight 17.6lbs
