Onkyo FRN 3 X Owners Manual
This is the 72 pages manual for Onkyo FRN 3 X Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Onkyo FRN 3 X Owners Manual (Ocr-read)
Page 1
2PORTABLE CART WARNINGS3125AImportant Safeguards1.Read Instructions – Read all safety and operating instruc- tions before operating the appliance. 2.Retain Instructions – Retain the safety and operating instructions for future reference. 3.Heed Warnings – Heed all warnings on the appliance and in the operating instructions. 4.Follow Instructions – Follow all operating and usage instructions. 5.Cleaning – Unplug the appliance from the wall outlet before cleaning. The appliance should be cleaned only as recom- mended by the manufacturer. 6.Attachments – Attachments not recommended by the manufacturer may create hazards. Use only recommended attachments. 7.Water and Moisture – Do not use the appliance near water –for example, near a bath tub, wash bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool, and the like. 8.Accessories – Do not place the appliance on an unstable cart, stand, tripod, bracket, or table.The appliance may fall, causing serious injury to a child or adult, and serious dam- age to the appliance. Use only with a cart, stand, tripod, bracket, or table recommended by the manufacturer, or sold with the appliance. Any mounting of the appliance should follow the manufacturers instructions, and should use a mounting accessory recommended by the manufacturer. 9. Move appliance and cart combinations with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to over- turn. 10.Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the appliance and to protect it from overheat- ing. Do not block or cover these openings by placing the appliance on a bed, sofa, rug, or other similar surface. Do not place the appliance in a built-in installation such as a bookcase or rack unless proper ventilation is provided. There should be free space of at least 20 cm (8 in.) and an opening behind the appliance. 11.Power Sources – The appliance should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your appliance dealer or local power company.12.Grounding or Polarization – The appliance may be equipped with a polarized alternating current line plug (a plug having one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fails to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. 13.Power-Cord Protection – Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon or against them. Pay particular atten- tion to cords at plugs, convenience receptacles, and the point at which they exit from the appliance. 14.Outdoor Antenna Grounding – If an outside antenna or cable system is connected to the appliance, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANSI/ NFPA 70, provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna-discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements for the grounding electrode. See Figure 1. 15.Lightning – For added protection for the appliance during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and dis- connect the antenna or cable system. This will prevent dam- age to the appliance due to lightning and power-line surges.16.Power Lines – An outside antenna system should not be located in the vicinity of overhead power lines or other elec- tric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to avoid touching such power lines or circuits as contact with them can be fatal.17.Overloading – Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire or electric shock.18.Object and Liquid Entry – Never push objects of any kind into the appliance through openings as they may touch dangerous voltage points or short-out parts, resulting in a fire or electric shock. Never spill liquid of any kind on the appliance.19.Servicing – Do not attempt to service the appliance your- self as opening or removing covers may expose you to dan- gerous voltage or other hazards. Refer all servicing to qualified service personnel.WARNINGRISK OF ELECTRIC SHOCK DO NOT OPENRISQUE DE CHOC ELECTRIQUE NE PAS OUVRIRAVISWARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated dangerous voltage within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Page 2
320.Damage Requiring Service – Unplug the appliance form the wall outlet and refer servicing to qualified service per- sonnel under the following conditions: A. When the power-supply cord or plug is damaged B. If liquid has been spilled, or objects have fallen into the appliance C. If the appliance has been exposed to rain or water D. If the appliance does not operate normally as per the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the appliance to its normal operation. E. If the appliance has been dropped or damaged in any way, and F. When the appliance exhibits a distinct change in perfor- mance – this indicates a need for service. 21.Replacement Parts – When replacement parts are required, be sure the service technician has used replace- ment parts specified by the manufacturer or that have the same characteristics as the original part. Unauthorized sub- stitutions may result in fire, electric shock, or other hazards. 22.Safety Check – Upon completion of any service or repairs to the appliance, ask the service technician to perform safety checks to determine that the appliance is in proper operating condition.23.Wall or Ceiling Mounting – The appliance should be mounted to a wall or ceiling only as recommended by the manufacturer. 24.Heat – The appliance should be situated away from heat sources such as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat. 25.Liquid Hazards – The appliance shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases shall be placed on the appliance. FIGURE 1: EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE, ANSI/NFPA 70Precautions1. Recording CopyrightRecording of copyrighted material for other than personal use is illegal without permission of the copyright holder.2. AC FuseThe fuse is located inside the chassis and is not user-service- able. If power does not come on, contact your Onkyo autho- rized service station.3. PowerWARNING BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY.The voltage of the available power supply differs according to country or region. Be sure that the power supply voltage of the area where this unit will be used meets the required voltage (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz) written on the rear panel.Setting the STANDBY button to standby mode does not shut off the power completely.4. Do not touch this unit with wet hands.Do not handle this unit or power cord when your hands are wet or damp. If water or any other liquid enters the case, take this unit to an authorized service center for inspection.5. Location of this unitPlace this unit in a well-ventilated location. Take special care to provide plenty of ventilation on all sides of this unit especially when it is placed in an audio rack. If ventila- tion is blocked, this unit may overheat and malfunction. Do not expose this unit to direct sunlight or heating units as this unit's internal temperature may rise and shorten the life of the pickup.Avoid damp and dusty places and places directly affected by vibrations from the speakers. In particular, avoid placing the unit on or above one of the speakers.Be sure this unit is placed in a horizontal position. Never place it on its side or on a slanted surface as it may malfunction.Do not place this unit near tuners or TV sets. If placed next to a TV or tuner, it may cause reception interfer- ence resulting in some noise in the TV or tuner output.6. CareFrom time to time you should wipe the front and rear panels and the cabinet with a soft cloth. For heavier dirt, unplug the power cord from the AC outlet, dampen a soft cloth in a weak solution of mild detergent and water, wring it out dry, and wipe off the dirt. Following this, dry the unit immediately with a clean cloth. Do not use rough material, thinners, alcohol or other chemical solvents or cloths since these could damage the finish or remove the panel lettering.7. Points to rememberIf this unit is brought from a cold environment to a warm one or is in a cold room that is quickly heated, condensation may form on the pickup, preventing proper operation. In this case, remove the disc and leave the power ON for about one hour to remove the condensation. When transporting this unit, be careful not to bump it.ANTENNA DISCHARGE UNIT (NEC SECTION 810-20)GROUNDING CONDUCTORS (NEC SECTION 810-21)GROUND CLAMPSPOWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H) NEC – NATIONAL ELECTRICAL CODEELECTRIC SERVICE EQUIPMENTGROUND CLAMPANTENNA LEAD IN WIRE S2898AUS and foreign patents licensed from Dolby Laboratories Licensing Corporation.CLASS 1 LASER PRODUCT This unit contains a semiconductor laser system and is classified as a CLASS 1 LASER PRODUCT. To use this model properly, read this Instruction Manual carefully. In case of any trouble, please contact the store where you purchased the unit. To prevent being exposed to the laser beam, do not try to open the enclosure.DANGER:INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK FAILED OR DEFEATED. AVOID DIRECT EXPOSURE TO BEAM.CAUTION:THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.This unit is a CLASS 1 LASER PRODUCT and employs a laser inside the cabinet. To prevent the laser from being exposed, do not remove the cover. Refer servicing to qualified personnel. 1. 2.This label on the left hand panel states that:
Page 65
66The following table explains the messages that appear in the display.MessagesMessage MeaningMD Blank Disc A recordable MD without disc or track names is inserted. Cannot Copy You tried to create a second digital copy from a digitally dubbed MD (see Rules for digital recording in the right column). Cannot Edit You tried to edit a playback-only disc. Cannot Rec You tried to record onto a playback-only disc. Cannot Set You tried to set a timer while another timer was operating. CD Dub Fail CD dubbing could not be activated. Complete The editing operation has been completed. Cannot Read The disc is abnormal (scratched or missing a TOC). Disc Full The disc is full (see System limitations on page 68). Full You tried to enter a character over the maximum character capacity while naming a disc, track, or group, etc. Impossible You tried to edit a disc using a function not available for some reason other than an MD system limitation. MD Writing The unit is writing the recorded or edited contents to the MD. Mecha Error An error occurred in the units internal mechanism. Memory Full You tried to store a 26th track or a 31st channel, exceeding the units capacity. Name Full The naming capacity of the disc or unit has reached its limit. No Change The name has not been changed. CD/MD No Disc There is no disc in the unit. Protected The inserted disc is record-protected. Recording You tried to switch to another source while recording, or to perform a CD or tuner operation that is dis- abled during recording. Retry Error The recording attempt failed due to consecutive disturbances from scratches on the MD or from applied vibration. Signal Wait The MD recorder has entered Signal Wait mode. Text Protect The CD text is copyrighted. Time Protect You tried to repeat double-speed dubbing using the same CD. TOC Error The unit failed to read or record onto a disc.Miscellaneous
