0 Congratulations on your purchase of the ONKYO DXE708/706 CD Player. 0 Please read
this manual thorough/y [re/ore making connections and turning power on. 0 Following the
instructions in this manual will enable you to obtain optimum performance and listening
ell/oyment from your new DXr708/ 706. 0 Please retain this manual for future reference

CONTENTS

Features ............................................
Important safeguards
Precautions ............... .
Before using this unit" .
System connections, ,,,,,,,,,,,
Control positions and names
Handling compact discs .......
Common modes of operation .. .. ..
Using the Memory function ..................................................................
Functions which can be operated only by using the remote control trans
Using the remote control transmitter,
Troubleshooting guide ,,,,,,,,,,,,,, , , , , ,
Specifications ...................................................................................................................

DNOLTIALOOJNJ

Features
-

o ONKYO Single-Bit D/A Converters
Instead of the "multi-bit" D/A converters employed in many CD players, the BX 708 and BX 706 use an innovative Slllgle'blln system.
It does away With the ladder network required by conventional high-bit" converters and, therefore, needs none of the delicate "trimming"
which such networks require to achieve even adequate linearity The operating pllnClpIe of the Single bit system assures far better linearity
than conventional D/A converters can ever achieve

0 Zero Shift Noise Shaper
The noise attenuation characteristics produced by the digital Ieedback configurations used in conventional nurse shapers are marked
by a continuous reduction from the high liequency range down through the low frequencies. In contrast to this, ONKYO's new Zero
Shift Noise Shaper employs a different feedback factor to produce not a continuous slope, but an attenuation pattern in which norse
is reduced to zero in the middle of the frequency range
The practical effect ol [his modilication is a measurable reduction in residual noise in the audio frequency range. compared wnh con
ventional designs The resulting improvement In the CD player's S/N ratio means more dynamic music reproduction, allowmg the listener
to hear delicate nuances which might have been missed otherWise. ONKYOs Zero Shift Norse Shaper heightens the small Signal lidelitv

of the sing|e~bit D/A conversion process for improved musicality with any program source

0 Complementary Distortion Canceler
C AccuPulse Quartz System
0 Center Mounted Disc Tray

In the DX-708 and DX-706, the central location of the disc drive mechanism serves to dii/ide the digital and analog crrcurt blocks Into
two discrete sections The DX-708 is even equipped with separate power supplies for the two sections, offering further protection against
mutual interference, This arrangement helps to prevent DSI (Digital Signal Interference) from leaking into the analog stage and also

contributes to improved stability for the chassis as whole

0 Dual AEI Power Transformers (DX-708)
' Newly Developed Linear Motor Actuator for Faster Access and Better Pickup Precision
I Diecast Aluminum Disc Tray
0 Opto-Coupling (BX-708)
O Eight-Times Oversampling Digital Filter
0 Peak Search Function Facilitates Making Recordings to Cassette Tape.
0 Optical Digital Output
0 Front Panel Dimmer Switch
0 RI Compatible Remote Control Included
0 Copper Plated Chassis (BX-708)
CAUTION "WARNING"

'TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR EACKI NO USERSERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL."

@-

RISK OF ELECTRIC SHOCK
DO NOT OPEN

0 The lightning Hash wilh arrowhead symbol, Within
an equilateral triangle, is intended to alert the user
to the presence or uninsuiated "dangerous voltage"
Within the products enclosure that may be at Suiilr
cient magnitude to constitute a risk at electric shock
to persons

0 The exclamation point Within an equilateral triangle
IS intended to alert the user to the presence ul imr
pmiani operating and maintenance (servicing) in~
Strucllons in the literature accompanying the appllr
ance,

"TO REDUCE THE RISK OF FIFIE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE,"

' For models having power cords With a polarized plug.

CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE
THIS (POLARIZED) PLUG WITH AN EXTENSION CORD, RE-
CEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.

0 Sur les modeles dont la fiche est polarisee.

ATTENTION: POUR PREVENIR LEs CHOCS ELECTRIOUES
NE PAS UTILISEFI CETTE FICHE POLARISEE AVEC UN PRO-
LONGATEUR, UNE PRISE DE COURANT DU UNEAUTRE SORTIE
DE COURANT, SAUF SI LES LAMEs PEUVENT ETRE INSEREES
A FOND sANs EN LAISSER AucUNE PARTIE A DECOUVERT,
