Onkyo DX 701 Service Manual

Page 1

Flat No. 3418
ONKYO® SERVICE MANUAL
COMPACT DISC PLAYER
Black and Silver models
BIIMD,BIIMDN,BHMDC 120V AC, 60Hz
BHMPJSHMPF, MP, MIF 230V AC, SOIIZ
BHMW 120/220V AC, 50/60Hz
BHMQA 240V AC,50H2
SAFETY-RELATED COMPONENT WARNINGI! SPECIFICATIONS
COMPONENTS IDENTIFIED BY MARK A ON THE Signal readout system: Optical non~contact
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE Reading rotation: About 500~200 r.p.m.
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. (constant linear velocity)
REPLACE THESE COMPONENTS WITH ONKYO PARTS Linear velocity: 1.2~1.4m/s
xHOSE PART NUMBERS APPEAR AS SHOWN IN THIS Error correction system: Cross interleave readsolomon code
ANUAL' D/ A converter: 1 bit PWM/Accu Pulse D/A converter
Sampling frequency: 352.8kH2 (8 times oversampling)
MAKE LEAKAGECURRENT OR RESISTANCE MEA- Number of channels: 2 (Stereo)
SUREMENTS TO DETERMINE THAT EXPOSED PARTS Frequency response: 5Hz~20kH2
ARE ACCEPTABLY INSULATED FROM THE SUPPLY Total harmonic distortion: 0.004% (at lkHz)
CIRCUIT BEFORE RETURNING THE APPLIANCE TO Dynamic range: 96dB
THE CUSTOM ER Signal to noise ratio: IOOdB
Channel separation: 90dB (at 1kI-Iz)
Wow and Flutter: Below threshold of measurability
Power consumption: 12 watts
Output level: 2 volts r.m.s.

Dimensions (WXHX D): 455 X 110x305mm
18"X4-3I8X12"
Weight: 4.9kg. 10.8lbs.

Specifications are subject to change without notice
