Onkyo DVSP 502 Service Manual
This is the 64 pages manual for Onkyo DVSP 502 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Onkyo DVSP 502 Service Manual (Ocr-read)
Page 1
DV-SP502/502E
Ref. No. 3830
ONKYO SERVICE MANUAL 2"
DVD PLAYER
MODEL DV-SP502
DV-S P502E
DV-SP502 Black, Golden and Silver models
RC-582DV RC-574DV
DV-SP502E Black and Silver models
MDD
120VAC,60H2 | MUP | 100-240V AC,50/60Hz
MUA, MUK, MUT
100-240V AC, 50/60Hz
SAFETY-RELATED COMPONENT
WA R N I N G ! !
COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
ONKYO®
IMAGINATIVE SIGHT & SOUND
