Onkyo DVSP 500 Service Manual

Page 1

P500

Ref. No. 3724

ONKYO SERVICE MANUAL 2°

DVD PLAYER
MODEL DV-SP500

UQU'GéQS
BQQ 0;
Daggm

(a
@993
0600
OQDQ
oego
@®OO

01668990
0100006)

,9.
G)
a
(D
O
G
(a
E)

n
3

K EQOVOQO® a o

/

(y-

ROAASDV Rcrqsoov
Us A Canaman Othev modes
mades only

Black, Silver and Golden models

B MDD, B MDC 120V AC, 60Hz
BMUIBMU&BMUP
G MUT, G MUS, G MUR, G MUK 110 - 240V AC, 50/60Hz
SMUP

SAFETY-RELATED COMPONENT
WARNING! !

THE MARK A FOUND ON SOME COMPONENT
PARTS INDICATES THE CRITICAL FOR RISK OF
FIRE AND ELECTRIC SHOCK.

WHEN REPLACING, BE SURE TO USE PARTS OF
IDENTICAL DESIGNATION.

MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

ONKYO®

IMAGINATIVE SIGHT & SOUND

Page 2

SPECIFICATIONS

General

DV-SP500

Power supply

Power consumption

Power consumption (standby mode)
Weight

External dimensions

Signal system

Regional restriction code

DVD Player

AC 100-240 V, 50/60 Hz
15 W

2.6 W

3.4 kg

435x 91 X 312 mm (W/H/D)
PAL/Auto mode

U.S.A. and Canadian area 1
Asia, Oseania and Korea area 3
South American area 4
Chinese area 6

Laser
Frequency range (digital audio)

Signal-to»noise ratio (digital audio)
Audio dynamic range (digital audio)
Harmonic distortion (digital audio)
Wow and flutter

Operating conditions

Outputs

Semiconductor laser, wavelength 650 nm

DVD linear sound: 48 kHz sampling 4 Hz to 22 kHz
96 kHz sampling 4 Hz to 44 kHz
Audio CD: 4 Hz to 20 kHz
More than 100 dB
More than 96 dB

Less than 0.015 %
Below measurable level (less than +/-0.001 % (W.PEAK))

Temperature: 5°C to 35°C, Operation status: Horizontal

Video output
S-video output

Component video output

Audio output (digital output Optical)
Audio output (digital output Coaxial)
Audio output (analog audio)

1.0 V (p-p), 75 ohm negative sync., pin jack X 1, SCART socket X1

(Y) 1.0 V (p-p), 75 ohm negative sync., Mini DIN 4-pin X1
(C) 0.286 V (p-p), 75 ohm SCART socket X1 only

RGB signal output, 0.7 V (pp), 75 ohm SCART socket x1 only
Optical connecter x 1
0.5 V (p-p), 75 ohm pin jack X1

2.0 V (rms), 470 ohm pin jack (L, R) X1, SCART socket X1 only
2.0 V (rms), 470 ohm pin jack (MONO) X1

Specifications and features are subject to change without notice.
