Onkyo DVCP 704 Service Manual

Page 1

DV-C P704

Ref. No. 3952

ONKYO SERVICE MANUAL 2"

DVD CHANGER
MODEL DV-CP704

[52".] =~..:..-4.¢.¢.¢.:u @.

\[Z:::7 - 7

@I
(O:

RC-655DV

Black and Silver models

BCDD, SCDD 120V AC, 60Hz
BCUA, SCUA 100-240V AC, 50/60Hz

SAFETY-RELATED COMPONENT
WA R N I N G ! !

COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.

MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

ONKYO.

IMAGINATIVE SIGHT & SOUND
