Onkyo DVC 701 Service Manual

This is the 87 pages manual for Onkyo DVC 701 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 87
Onkyo DVC 701 Service Manual

Extracted text from Onkyo DVC 701 Service Manual (Ocr-read)


Page 1

-CP701

Ref. No. 3760

ONKYO SERVICE MANUAL °52°°3

DVD CHANGER
MODEL DV-CP701

RC-542DV

Black and Silver models

B MDD, S MDD 120V AC, 60Hz
B MPA 220-230V AC, 50/60Hz

SAFETY-RELATED COMPONENT
WARNING! !

COMPONENTS IDENTIFIED BY MARK A ()N THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ()NKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.

MAKE LEAKAGE-CURRENT 0R RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

ONKYO.

IMAGINATIVE SIGHT & SOUND
