Page 1
2 IMPORTANT INFORMATION Precautions Please read this manual carefully before using your Integra Projector DLV-100 and keep the manual handy for future reference. Your serial number is located on the bottom of your DLV-100. Record it here: CAUTION To turn off main power, be sure to remove the plug from power outlet. The power outlet socket should be installed as near to the equipment as possible, and should be easily accessible. CAUTION TO PREVENT SHOCK, DO NOT OPEN THE CABINET. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SER- VICE PERSONNEL. This symbol warns the user that uninsulated voltage within the unit may be sufficient to cause electrical shock. Therefore, it is dan- gerous to make any kind of contact with any part inside of the unit. This symbol alerts the user that important in- formation concerning the operation and main- tenance of this unit has been provided. The information should be read carefully to avoid problems. WARNING TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO NOT USE THIS UNITS GROUNDED PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THREE PRONGS CAN BE FULLY INSERTED. DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLT- AGE COMPONENTS INSIDE. ALL SERVICING MUST BE DONE BY QUALIFIED SERVICE PERSONNEL. DOC Compliance Notice This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regula- tions. RF Interference WARNING The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by Integra Technologies in this manual. Failure to comply with this government regulation could void your right to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful in- terference in a residential installation. This equipment generates, uses, and can radiate radio frequency en- ergy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guaran- tee that interference will not occur in a particular in- stallation. If this equipment does cause harmful inter- ference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit dif- ferent from that to which the receiver is connected. - Consult the dealer or an experienced radio / TV tech- nician for help. - IBM is a registered trademark of International Business Machines Corporation. - Macintosh and PowerBook are registered trademarks of Apple Computer, Inc. - Other product and company names mentioned in this instruction manual may be the trademarks of their respective holders.
Page 2
3 Important Safeguards These safety instructions are to ensure the long life of your projector and to prevent fire and shock. Please read them carefully and heed all warnings. Installation 1. For best results, use your projector in a darkened room. 2. Place the projector on a flat, level surface in a dry area away from dust and moisture. 3. Do not place your projector in direct sunlight, near heaters or heat radiating appliances. 4. Exposure to direct sunlight, smoke or steam can harm in- ternal components. 5. Handle your projector carefully. Dropping or jarring can dam- age internal components. 6. Do not place heavy objects on top of the projector. 7. If you wish to have the projector installed on the ceiling: a. Do not attempt to install the projector yourself. b. The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk of bodily injury. c. In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance with any local building codes. d. Please consult your dealer for more information. Power Supply 1. The projector is designed to operate on a power supply of 100-120 or 200-240 V 50/60 Hz AC. Ensure that your power supply fits this requirement before attempting to use your projector. 2. Handle the power cable carefully and avoid excessive bend- ing. A damaged cord can cause electric shock or fire. 3. If the projector is not to be used for an extended period of time, disconnect the plug from the power outlet. CAUTION Do not unplug the power cable from the wall outlet under any one of the following circumstances. Doing so can cause damage to the projector: * While the Hour Glass icon appears. * While the message "Please wait a moment." appears. This mes- sage will be displayed after the projector is turned off. * Immediately after the power cable is plugged into the wall outlet (the POWER indicator has not changed to a steady or- ange glow). * Immediately after the cooling fan stops working (The cooling fan continues to work for 90 seconds after the projector is turned off with the POWER button). * While the POWER and the STATUS indicators are alternately flashing.
Page 13
14 2. INSTALLATION This section describes how to set up your projector DLV-100 and how to connect video and audio sources. Setting up Your Projector Your Projector DLV-100 is simple to set up and use. But before you get started, you must first: 1. Determine the image size. 2. Set up a screen or select a non-glossy white wall onto which you can project your image. Ensure that the power cable and any other cables connecting to video sources are disconnected before moving the projector. When moving the projector or when it is not in use, cover the lens with the lens cap. Selecting a Location The further your projector is from the screen or wall, the larger the image. The minimum size the image can be is approximately 30" (0.8 m) measured diagonally when the projector is roughly 4 feet (1.3 m) from the wall or screen. The largest the image can be is 200" (5.1 m) when the projector is about 29 feet (8.8 m) from the wall or screen. Screen and Projection Distance The following shows the proper relative positions of the projector and screen. Refer to the table to determine the position of installation. 406.4(W) X 304.8(H) / 160(W) X 120(H) 365.8(W) X 274.3(H) / 144(W) X 108(H) 304.8(W) X 228.6(H) / 120(W) X 90(H) 243.8(W) X 182.9(H) / 96(W) X 72(H) 203.2(W) X 152.4(H) / 80(W) X 60(H) 162.6(W) X 121.9(H) / 64(W) X 48(H) 121.9(W) X 91.4(H) / 48(W) X 36(H) 81.3(W) X 61.0(H) / 32(W) X 24(H) 61.0(W) X 45.7(H) / 24(W) X 18(H) Screen size (Unit: cm / inch) Lens center 1.7 / 67 2.6 / 102 3.5 / 138 4.4 / 173 5.3 / 209 6.6 / 260 7.9 / 311 8.8 / 346 1.3 / 51 200"Screen 180" 150" 120" 100" 80" 60" 40" 30" Throwing distance Unit: m / inch
Page 19
20 AC IN PC CARD USB VIDEO S-VIDEO RGB AUDIO PC CONTROL MENU ENTERCANCELSELECT A U T O A D J U S T P C C A R D A C C E S S S T A T U S P O W E RO N/ S T A N D B YS O U R C E VIDEO S-VIDEO RGB AUDIO PC CONTROL VIDEO S-VIDEO R L R L VIDEO Use common RCA cables (not provided) to connect your VCR, laser disc player or document camera to your projector. To make these connections, simply: 1. Turn off the power to the projector and VCR, laser disc player or document camera. 2. Connect one end of your RCA cable to the video output connector on the back of your VCR or laser disc player, connect the other end to the Video input on your projector. Use an audio cable (not supplied) to connect the audio from your VCR or laser disc player to your audio equipment (if your VCR or laser disc player has this capability). Be careful to keep your right and left channel connections correct for stereo sound. 3. Turn on the projector and the VCR or laser disc player. NOTE: Refer to your VCR or laser disc player instruction manual for more information about your equipments video output requirements. NOTE: - The image from a video playback deck may not be correctly displayed when used with a scan converter before being input to the projector. VCR/ Laser disc player Connecting Your VCR or Laser Disc Player S-video cable (not supplied) Audio cable (not supplied) Audio equipment Document camera Video cable (not supplied) Red White Red White
