Onkyo A 9355 Service Manual
This is the 66 pages manual for Onkyo A 9355 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Onkyo A 9355 Service Manual (Ocr-read)
Page 1
Ref. No. 3982
ONKYO SERVICE MANUAL °32°°7
INTEGRATED AMPLIFIER
MODEL A-9355
RC-627S
Black, Silver and golden models
B MPP 230V AC, SOHZ
S MPP 230V AC, 50Hz
G MGT 220-230V AC, 50/60Hz
G MDT 120V AC, 60Hz
G MGR 220-230V AC, 50/60Hz
SAFETY-RELATED COMPONENT
WA R N I N G ! !
COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT 0R RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
ONKYO®
IMAGINATIVE SIGHT SI SOUND
