Onkyo A 9155 Service Manual

This is the 10 pages manual for Onkyo A 9155 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 10
Onkyo A 9155 Service Manual

Extracted text from Onkyo A 9155 Service Manual (Ocr-read)


Page 1

Ref. No. 3991

ONKYO SERVICE MANUAL °2°°

INTEGRATED AMPLIFIER
MODEL A-9155

RC-627S

Black and Silver models

B MPP 230V AC, 50Hz
S MPP 230V AC, 50Hz

SAFETY-RELATED COMPONENT
WA R N I N G ! !

COMPONENTS IDENTIFIED BY MARK A ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.

MAKE LEAKAGE-CURRENT 0R RESISTANCE
MEASUREMENTS To DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.

ONKYO®

IMAGINATIVE SIGHT SI SOUND
