Nikko NT 890 Service Manual

Page 2

GAUTIDNS
-

Thank you very much for selecting the Nikko NT-890.
Incorporating the most advanced circuit technology, every
Nikko product also passes a rigid series of tests before reach-

ing the audio fan.

In order to derive the maximum performance from this unit,
be sure to read this manual carefully and to follow its

instructions fully.

Installation;

In order to be sure you derive the maximum service
from this unit, please pay attention to the following
points, which are often the cause of damage or reduced

performance.

0 Avoid placing the unit in a location exposed to
direct sunlight or heat, such as in front of a heater.

0 Avoid a location with insufficient ventilation. or
one exposed to moisture or dampness.

0 Avoid locations which are dusty or dirty.

0 Make Sure the unit is mounted on a flat. stable
surface. free from vibrations.

i. This unit is designed so that heat created during

operation is dissipated through the ventilation
openings in the top and bottom panels. Maintain

CONTENTS

Stereo System Arrangement ..................
Operating Parts ...........................

Connecrions and Operation

PreMain Amplifier Connection ..........
AM Antenna Connection ..............
AM Reception .....................
FM Antenna Connection ...............
Coaxial Cable Connection ..............
The Selector Switch ..................
The Multipath Switch .................
FM Reception ......................
Specifications ............................

tree and unreStricted ventilation by making sore
you do not remove the feet from the bottom
plate, or c0ver the ventilation openings in any way
lsuch as stacking another stereo component on
top, or installing on a shell too small for proper
ventilation). To be sure of Sufficient ventilation.
allow at least 5 cm space on all sides.

If the cabinet becomes dirty, wipe it with a soft
cloth. Do not let alcohol. thinner, benzine,
insecticides or petroleum produCts come into
contact with the cabinet.

If repaires become necessary, see your nearest
Nikko service center or dealer.

_-,

WARNING : To avoid the danger of fire or damage,

protect the set from rain and dampness.

................................ 3
vvvvvvvvvvvvvvvvvvvvvvvvvvvvvvvv '

................................ 5
................................ 5
................................ 5
................................ 5
................................ 5
................................ 6
................................ 6
................................ 6
................................ 7
