EXPLANATION FOR FUNCTION OPERATION

POWER

To turn the tuner on and off.

OUTPUT LEV EL
This control determines the output level of the tuner.

IF BAND

This switch controls the selectivity of the IF band.
When the signal being received is disturbed by nearby
stations, press this switch to NARROW position for
elimination of interference.

Hl-B LEND

Press this switch to eliminate high frequency noise
from incoming signals.

MODE

This switch is used to select the mode of reception.
When it is set to MONO position, FM reception is
heard in monaural and the Stereo Indicator lamp will
be off.

This switch also functions as a muting switch. When
selecting stations, set the switch to STEREO and
interstation noise will be eliminated.

An indicatinglamp will lidit when the switch is in the
STEREO position. Press this switch to MONO position
for stations with weak signals.

SIGNAL METER

This meter indicates the signal strength of the FM
station being received.

TUNING METER

This meter is used for awurate FM tuning. Turn the
tuning knob to the desired station until the TUNING
meter indicates the center" position. At the same
time, the SIGNAL meter will deflect maximum.

STEREO INDICATOR

This lamp will light when stereo reception is tuned
accurately.

TUNING KNOB

Turn this knob to select the desired station. Observe
both SIGNAL and TUNING meters for accurate
readings.
