Nikko beta 2 pre sm

Page 2

OPERATING PARTS

POWER and 2. PILOT LAMP

To turn on the power, set the power switch to the
ON position. The pilot lamp will light, indicating
that the-power is on. The unit will become active a
few seconds later because of the employment of a
built-in relay.

BASS
To increase bass tone, turn this control clockwise.
The tone is flat at the center (DEFEAT) position.

TREBLE
To increase treble tone, turn this control clockwise.
The tone is flat at the center (DEFEAT) position.

BALANCE

This control adjusts unbalance of volume between
the left and right channels. Turning the control to
left will increase the volume of left channel while
decreasing the volume of right channel, and vice
versa.

VOLUME

The 42-position, dual volume control adjusts the
volume of both the left and right channels simul»
taneously with minimum error. Turning the knob
clockwise will increase volume.

TAPE

This switch is used for tape playback or tape dub»

bing.

PLAY 1: For playing tape with tape deck con-
nected to TAPE 1 terminals.

PLAY 2: For playing tape with tape deck con-
nected to TAPE 2 terminals.

For tape dubbing from one tape deck to another,

simply set the switch to DUB1-2 0f DUB 2-1

position.

When you are not using tape deck, set the switch to

SOURCE position.

10.

'll.

AUDIO MUTING

By pressing this switch, the level of the signal fed to
your power amplifier is reduced to -20dB (1/10).
If you wish to reduce the volume for a brief period
of time, simply press the switch until locks.

This feature is also useful for fine adjustment of
volume control while listening at low volume. In
this case, the volume control is normally set at the
approximate center position.

SUBSONIC FILTER
Pressing this switch to ON will shut off extremely

low frequency noise possibly generated from
warped records.

PHONO IMPEDANCE Selector Switch

This 3-position switch selects the impedance of
record player cartridge being used, 22K, 47K or
100K ohms. Normally, it is set to the 47" position.

SELECTOR
This switch is used to select and program source
connected to the input terminals.

AUX: For playback of program connected to
to AUX input.

TUNER: For reception of broadcast with stereo
tuner.

PHONO 1,2: For playback with record player.
