Page 1
nothing short of stunning. Even standard de nition DVDs get a boost from NADs upscaling engine with resolution to 1080p. The T 587 also supports 1080p at 24 frames per second for the most uid motion from lm based material (this must be supported by the TV display) avoiding the 3:2 Pull Down motion artifacts common on DVD Players. Audio Performance Most Blu-ray Discs offer a true high de nition audio 7.1 Linear PCM soundtrack with 24 bit resolution, and the T 587 supports this format via HDMI. At last we have studio master quality in a home format! Also supported are the new HD formats from Dolby and DTS that offer lossless compression. These can be decoded in the T 587 and sent as LPCM via HDMI, or can be forwarded in compressed form to another component that supports decoding. Of course the legacy formats of Dolby Digital and DTS are also supported and sent as bitstreams via HDMI, Coax or Optical connections. Dolby Digital Plus is a new and backwardly compatible Dolby format that increases the bit rate considerably for improved delity and also offers support for up to 10.2 channels. There is also support for Audio CDs and CD-Rs with MP3 or WMA decoding. There is even a front panel USB port to allow playback of music les stored on a memory stick or portable MP3 Player. Exciting new features BD Java and BD Live, when supported by the source material, offer a new level of interactivity with your media. BD Live will connect over a broadband network to the studio that produced the movie you are watching and will offer additional material and alternate takes in real time to your Home Theatre. Details that matter The T 587 has a very fast loading time for Blu-ray Discs, typically just a few seconds. Many BD players take over a minute before you can get picture, sound and navigation. This may not sound like much, but it seems an eternity if you are waiting to start watching your favorite movie. Other nice touches not commonly found include an external IR Input for integration with advanced control and automation systems. Specially developed silicon rubber feet isolate vibrations from the player and the environment for the best possible performance. With onboard decoding for the newest lossless audio codecs from Dolby and DTS the T 587 will provide a complete HD audio and video solution to thousands of NAD T 175, T 785 and T 775 AV Receiver owners. This cost effective upgrade, when combined with the current generation of 1080p displays creates a state-of-the-art Home Theatre. > DETAILS T 587 Blu-ray Disc Player SYSTEM Signal system Auto/NTSC/PAL Laser Semiconductor laser Frequency response ±2dB (ref. 0dB 20 Hz – 20 kHz) Signal-to-noise ratio >100dB (A-WTD, analogue OUT) Dynamic range >95 dB Total Harmonic Distortion <0.008 % LAN port Ethernet jack, 10 Base-T/100 Base-TX OUTPUT Output format Video OUT: up to 480i/576i Component video OUT: up to 1080i HDMI OUT: up to 1080p Video out 1Vp-p/75 Ω S-Video (Y signal) 1Vp-p/75 Ω S-Video (C signal) 0.3Vp-p/75 Ω Component (Y signal) 1Vp-p/75 Ω Component (Cb/Cr signal) 0.7Vp-p/75 Ω Audio output level 2.0 Vrms (ref. 1 kHz, 0 dB) HDMI version 1.3 Digital out (coaxial) 0.5Vp-p Digital out (optical) 3Vp-p GENERAL Power requirements AC 120 V 60 Hz (120V version model) AC 120V - 230 V 50/60 Hz (230V version model) Unit Dimension (W x H x D) 17 1/8 x 2 3/8 x 11 435 x 60 x 280 mm (Gross)* Net weight 7.71 lbs (3.5 kg) Shipping weight 11.24 lbs (5.1 kg) * Gross dimensions include volume knob / speaker ternimals / connectors\ / feet. Note: Installers should allow a minimum clearance of 2- 4 inches for wir\ e managment. > SPECIFICATIONS
Page 2
T 587 Blu-ray Disc Player NAD Electronics International reserves the right to change specifications or features without notice. NAD is a registered trademark of NAD Electronics International. All rights reserved. No part of this publication may be reproduced, stored, or tr ansmitted in any form whatsoever without the written permission of NAD Electronics International. © 10/08 NAD Electronics International. www.NADelectronics.com > SPECIFICATIONS
