Extracted text from Nad T 163 Technical Bulletin (Ocr-read)
Page 1
Page 2 of 2 Technical Bulletin T163 Product: A/V Receiver Hardware Technical Bulletin: T163-H2005-05R Figure 2 Contact: NAD Electronics International 633 Granite Court Pickering, ON Canada L1K 3K1 Voice: 905-831-0799 FAX 905-837-6357 www.nadelectronics.com 4700pF surface mount capacitor between base and collector pins of muting transistor on the pre amp pc board
Page 2
Page 1 of 2 Technical Bulletin T163 Product: A/V Receivers Hardware Technical Bulletin: T163-H2004-01 Date:June 15 , 2004 Subject: Flat Ribbon Cables Note: Previous T.B.s required: TYES TNO DESCRIPTION: The unit may be experiencing intermittent audio or display. The unit may not always power up. REASON: The flat ribbon cables, primarily the ones running from the front panel but may include all flat ribbon cables. They may have intermittent contact due to oxidization. SOLUTION: Clean all ribbon connectors using an eraser or preferably a non alcohol based cleaner which will leave no residue. See figures 1, 2 and 3. Figure 1 Locate and remove the ribbon cables, front panel cables shown.
