information to the listener. The track number is displayed, and for those who regularly record CDs, Vacuum Fluorescent display shows the current time elapsed or remaining for complete CDs or individual tracks. Not all digital outputs are equal. In the case of the NAD C 545BEE, careful attention has been paid so that best use can be made of the ever increasing number of products now available with digital inputs (CD, MD recorders, computer sound cards, outboard D to A converters, etc.). Unusually at this price point, the coaxial output is buffered and isolated by a transformer from the converter itself and the output impedance has been carefully tailored to produce a precise 75 Ohms impedance to ensure perfect matching. This attention to detail reduces the timing errors (jitter) that could otherwise distort the digital data stream. An optical Toslink output is also provided allowing connection to devices that only provide this option.The Model C 545BEE comes supplied with the new NAD CD-8 full function remote control, offering all of the features described above from the comfort of your listening chair. On top of that, the remote control handset gives you direct track access and programming facilities, as well, saving the users time when theyre storing preferred song titles. Up to 40 tracks can be programmed. It is possible to delete tracks without using the program function by simply using the CLEAR key. Separate power regulators for the digital and analog sections isolate the two electrically, reducing interference effects. Furthermore, careful layout of the PCB tracks around the Digital-to-Analogue converter helps to contain RF radiation and interference. The 24 bit high resolution Burr Brown Digital-to-Analogue converter chip was chosen for its excellent low-level linearity and detail retrieving capabilities. Metal lm resistors and polypropylene capacitors are used in key areas to ensure a highly accurate frequency response. High quality Burr Brown OPA2134 op-amps are used instead of the much lower grade and type used in lesser players. Apart from the single lm type output capacitor, no other capacitors are used in the signal path. The output impedance is very low at 300 ohms, making the NAD C 545BEE less sensitive to cables or the ancillary equipment it is partnered with. We urge you to listen to the NAD C 545BEE with a wide range of program material and with the best ancillary equipment to fully appreciate the re nement of this modest looking – and by High End standards inexpensive – CD player. You can spend a lot more money for a CD player, but we think youll have a dif cult task nding a more musically complete and rewarding performance than that offered by the NAD C 545 BEE. A new benchmark has been set. > DETAILS C 545BEE CD Player > SPECIFICATIONS GENERAL PARAMETERS Output level Analog 2.2 ± 0.1 V Optical -22.5 ± 3.5 dBm Coaxial 650 ± 150 mV Frequency response ± 0.3 dB (ref. 0 dB 20 Hz-1 kHz) ± 0.5 dB (ref. 0 dB 1 kHz-20 kHz) Total harmonic distortion <0.01 % (ref. 1 kHz) Signal/Noise ratio 118 dB (A-weighted, ref. 1 kHz) Channel balance ± 0.5 dB(ref. 0 dB 1 kHz) Dynamic range >95 dB Channel separation >90 dB De-emphasis -3.73 to -5.33 dB (ref.0 dB 5 kHz) -8.04 to -10.04 dB (ref.0 dB 16 kHz) Linearity (ref. 0 dB 1 kHz) ± 0.01 dB (at -3 dB) ± 0.02 dB (at -6 dB) ± 0.05 dB (at -20dB) ± 0.15 dB (at -60dB) PHYSICAL SPECIFICATIONS Dimensions (W x H x D) Net 435 x 70 x 285 mm 17 1/8 x 2 3/4 x 11 1/4 Gross 435 x 86 x 293 mm 17 1/8 x 3 3/8 x 11 1/2 Net weight 10.80 lbs (4.9 kg) Shipping weight 13.89 lbs (6.3 kg) * Gross dimensions include volume knob / speaker ternimals / connectors\ / feet. Note: Installers should allow a minimum clearance of 2- 4 inches for wir\ e managment.
Page 2
C 545BEE CD Player NAD Electronics International reserves the right to change specifications or features without notice. NAD is a registered trademark of NAD Electronics International. All rights reserved. No part of this publication may be reproduced, stored, or tr ansmitted in any form whatsoever without the written permission of NAD Electronics International. © 10/08 NAD Electronics International. www.NADelectronics.com > REAR LINE DRAWING
