Nad C 340 Service Manual

This is the 19 pages manual for Nad C 340 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 19
Nad C 340 Service Manual

Extracted text from Nad C 340 Service Manual (Ocr-read)


Page 2

SERVICE SAFETY PRECAUTIONS

l. Replacing the fuses
CAUTION: FOR CONTINUED PROTECTION AGAINST THE RISK OF FIRE
REPLACE ONLY WITH SAME TYPE OF FUSE.

Reference No. Part No. Description

F901*AH 252163 4A~125V UL/T-237 Time lag

F901*Bl, B, 0 252074 T2A L/250V SE-EAK Time lag

NOTE:

<*AH> : U.S.A. CANADIAN MODEL ONLY, (*BI) : AUSTRALIAN MODEL ONLY.
<*C> : EUROPEAN MODEL ONLY. (*3) : U.K. MODEL ONLY.

2. SAFETY CHECK OUT
(Only U.S.A. model)
Before returning the product to the customer, make leakage current or resistance
measurements to determine that exposed parts are acceptably insulated from the
supply circuit.

Parts marked with the symbol A are critical with regard to the risk of fire and
electric shock. Replace only with parts recommended by the manufacturer.

CONTENTS

DESCRIPTION PAGE
SERVICE SAFETY PRECAUTIONS """""""""""""" 2
FRONT PANEL / REAR PANEL VIEW 3
SPECIFICATIONS """""" 4
ALIGNMENT PROCEDURE - 5
WIRING DIAGRAM ------------------------------------ 6
BLOCK DIAGRAM ------------------------------------- 7
MICROPROGESSOR CONNECTION DIAGRAM 8
SCHEMATIC DIAGRAM ------------------ 9-10
PCB LAYOUT ----- 11-12
IC BLOCK DIAGRAM . 13
EXPLODED VIEW """""" 14
EXPLODED VlEW PARTS LIST 15-16
ELECTRICAL PARTS LIST ------- 17-18
PACKING DIAGRAM / PARTS LIST ---------------------- 19
