Nad 5420 Owners Manual
This is the 6 pages manual for Nad 5420 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Nad 5420 Owners Manual (Ocr-read)
Page 1
NOTE: Some NAD products are equipped with dual or multi voltage transformers (which is indicated on the back panel). If you wish to change the voltage, please bring your unit to an authorised NAD service technician for internal conversion. ATTENTION: Quelques pieces NAD sonl munies de transformateurs a double au it mUlti -voltage (indique au panneau arriere). Si vous voulez changer Ie voltage, v euillez apporter votre appareil au fourn isseur de NAO pour Ie transformer. ZUR BEACHTUNG: Einige NAD Gerate sind mit Umscha ltern fOr unterschiedliche Netzspannungern ausgerustet (Ein Vermerk auf der ROckseite weist darauf hin ). Die Anpassung, wenn notwendig , muB von einem qualifizieren Techniker in einer NAD Servicestation vorgenommen werden. NOTA: Ciertos componentes de NAD estan dotados de transformadores de dobre tension 0 de varias tensiones (10 que se indica en el panel posterior). Si se desea cambiar la tensi6n, sfrvanse Ilevar el aparato a un tecnico autorizado par NAD para su conversi6n interna. WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE . ADVERTENICIA: PARA EVITAR EL RIESGO DE INCENDIO 0 SACUDIDA ELECTRICA , NO DEBERA EXPONERSE ESTE APARATO A LA LLUVIA 0 HUMEDAD . NOTE to CATV systems Installer: This reminder is provided to call the CATV system installer's attenlion to Articie 820-22 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as ciose to the point of cable entry as practical. NOTA PARA EL INSTALADOR DE ANTENAS DE TELEVISION COLECTIVAS: La presente advertencia se provee para lIamar la atenci6n del instalador al Articulo 820-22 de NEC (C6rdigo Electrico Nacional) donde se facilitan las directrices para la pertinente puesta a tierra y que especifica en particular que el condutor a tierra del cable debe conectarsa al sistema de conexion a tierra del edificio, 10 mas proximo posible al punta de entrada del cable . CAUTION : TO PREVENT ELECTRIC SHOCK DO NOT USE THIS (POLARISED) PLUG WITH AN EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. ATTENTION : POUR PREVENIR LES CHOCS ELECTRIQUES NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN PROLONGATEUR. UNE PRISE DE COURANT OU UNE AUTRE SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS EN LAISSER AUCuNE PARTIE FOND SANS EN LAISSER AUCUNE PARTIE A DECOUVERT. PRECAUCION: PARA EVITAR SACUDIDAS ELECTRICAS, NO DEBERA UTILIZARSE ESTA CLAVIJA POLARIZADA CON UN CORDON DE PROLONGACION, RECEPTACULO U OTRO TIPO DE SALIDA A MENOS QUE SE HAYAN INSERTASO COMPLETAMENTE LAS LENGOETAS PARA EVITAR SU EXPOSICION. NAD ELECTRONICS LONDON
Page 2
---- ------------------- CAUTION: THIS DIGITAL AUDIO COMPACT DISC PLAYER CONTAINS A LASER SYSTEM AND IS CLASSIFIED AS A CLASS 1 LASER PRODUCT . TO USE THIS MODEL PROPERLY , READ THE OWNER'S MANUAL CAREFULLY, AND KEEP IT FOR FURTHER REFERENCE. IN CASE OF ANY TROUBLE WITH THE UNIT, PLEASE CONTACT AN AUTHORISED NAD SERVICE STATION. DO NOT OPEN THE ENCLOSURE , TO PREVENT BEING EXPOSED TO THE LASER BEAM. CAUTION : USE OF THE CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED IN THE OWNER'S MANUAL MAY RESULT IN HAZARDOUS RADIATION EXPOSURE . THIS PRODUCT COMPLIES WITH DHHS RULES 21 CFR SUBCHAPTER J PART 1040.10 AND 1040 . 11 AT DATE OF MANUFACTURE MANUFACTURED : CLASS 1 LASER PRODUCT SPECIRCA nONS· NAD 5420/25 COMPACT DISC PLAYER Disc capacity Programming capability Digital-to-Analogue Conversion Digital filter Single disc, 120 or BO mm 16 tracks MASH , 1 B-bit resolution . 4 times oV9r~sampled. linear phase w~h 18-b~ coefficients Analogue !mer 5-pole active Frequency response 5 Hz - 20 kHz: -o1-{).5 dB De-Emphasis error < ±0.3 dB THO (at 0 dB, 1 kHz) 0.0025% Intermodulalion distortion < -1 00 dB (19 & 20 kHz) Dynamic range Linearity Signal-to-noise ratio A weighted de -emphasis off de-emphasis on Channel separation 1 kHz 10 kHz Wow and flutter Output impedance Output level at 0 dB Digital error correction Physical specifications Width x height x depth Net weight Shipping weight 9B dB ±0.5 dB ; 0 to -90 dB 106 dB 110 dB >100 dB > 80 dB Unmeasurable (quartz crystal accuracy) 120 Ohms 2VRMS CIRC with double error correction in C1 and C2 420 x 90 x 260 mm 4.1Kg 4.9Kg Specifications are those in effect at the time of printing. NAD reserves the right to change specffications or designs at any time w~hout notice . 55351 2253 3
