Page 1
SPECIFICATIONS - NAD 514 Disc capacity Single disc 120mm or 80mm Programming capability 20 Tracks Digital-to-Analogue conversion 18 bit 4 x oversampled Analogue filter 5 pole active Frequency response 5Hz-20kHz ±0.2dB De-emphasis error <0.2dB THD (at odB, 1kHz) 0.002% Dynamic range 98dB Linearity +0.5dB; 0 to -90dB Signal to noise ratio (A-weighted, measured with all zeroes test disc) >100dB Channel separation @ 1kHz >110dB Wow and Flutter Unmeasurable (Quartz accuracy) Output impedance 120 Output level @ 0dB 2.0V rms Digital error correction CIRC with double error correction in C1 and C2 Digital code output Sony/Philips serial data format Remote control yes PHYSICAL SPECIFICATIONS Dimensions (W x H x D) 435 x 95 x 290 mm Net weight 4.6kg Shipping weight 5.5kg NOTE: NAD resrves the right to change specifications or design at any time without notice. All specifications sre those in effect at time of printing. MASH is a registered trademark of Matsushita Laboratories Ltd.
