Nad 402 Service Manual
This is the 20 pages manual for Nad 402 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Nad 402 Service Manual (Ocr-read)
Page 2
TABLE OF CONTENTS
SPECIFICATIONS ................................... 1
REAR PANEL ..................................... 3
FRONT PANEL .................................... 3
ALIGNMENT PROCEDURE
FM Tuner .................................... 4
AM Tuner .................................... 5
Instrument Set-up ............................... 6
l0 BLOCK DIAGRAMS ................................. 7
PCB LAYOUTS .................................... 8
WIRING DIAGRAM ................................... 9
SCHEMATlC DIAGRAMS
Tuner ..................................... 10
Display ..................................... 11
EXPLODED VIEW .................................. 12
EXPLODED VlEW PARTS LIST - , - : ----------------------- 13
ELECTRICAL PARTS LlST ------------------------------ 14
PACKING DIAGRAM .................................. 17
SERVICE SAFETY PRECAUTIONS
1 Use exact replacement parts for critical locations, marked A on parts list.
2. Return lead dress to original position, and re-install protective covers
3. Before returning to customer, test for shock hazard; use either method A or B:
A. Leakage test, "cold":
Unplug AC cord, turn power switch ONT
Connect one lead of High Voltage Insulation Tester to both prongs of AC plug.
Touch other lead to all exposed metal parts.
Impedance measurement must be 03 - 50 Megohms.
iPNT
F
Leakage test, "live":
Plug unit directly into AC outlet; do not use isolation transformer.
Connect one lead of Leakage Current Tester to earth ground.
Touch other lead to all exposed metal parts.
Leakage measurement must be less than 0.5 milliamps,
P999)?
