Nad 302 Service Manual
This is the 19 pages manual for Nad 302 Service Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Nad 302 Service Manual (Ocr-read)
Page 2
CONTENTS
DESCRIPTION PAGE
SPECIFICATIONS .................................................... 3
REAR PANEL/FRONT PANEL VIEW ..................................... 4
BLOCK DIAGRAM ................................................... 5
WIRING DIAGRAM ................................................... 6
AMPLIFIER ADJUSTMENT ............................................ 7
TROUBLE SHOOTING GUIDE ......................................... 8
SCHEMATIC DIAGRAM ............................................. 9-10
PCB LAYOUT (PARTS SIDE) ........................................ 11-12
EXPLODED VIEW .................................................. 13
EXPLODED VIEW PARTS LIST ........................................ 14
DISASSEMBLY INSTRUCTIONS ....................................... 15
PARTS LIST ..................................................... 16-18
PACKING DIAGRAM ................................................. 19
SERVICE SAFETY PRECAUTIONS
1. Use exact replacement parts for critical locations, marked " A " on parts list.
2. Return lead dress to original position, and re-install protective covers.
3. Before returning to customer, test for shock hazard; use either method A or B:
A. Leakage test, cold:
Unplug AC cord, turn power switch ON.
Connect one lead of High Voltage Insulation Tester to both prongs of AC plug.
Touch other lead to all exposed metal parts.
Impedance measurement must be 0.3 - 5.0 Megohms.
PWIVT
Leakage test, live:
Plug unit directly into AC outlet; do not use isolation transformer.
Connect one lead of Leakage Current Tester to earth ground.
Touch other lead to all exposed metal parts.
Leakage measurement must be less than 0.5 milliamps.
9.9!?
