Page 2
PACKING DIAGRAM
'1
f
I
PACKING LIST
lte Part No Description Qty
30 N14971062-0 MANUAL POLYBAG 1
31 1490-1853-0 POLYFORM ENDCAP 2
32 N43013604-1 INSTRUCTION MANUAL 1
33 1497-1482-0 EPE BAG 1
34 1476-3701-0 CARTON BOX 1
Proprietary information for servicing purposes only. The information herein may not be used
commercially without the prior written agreement of NAD Electronics Ltd., London, England.
34
Page 5
DIAGRAM 3 - BRIDGE MODE, UNBALANCED MODE (RCA input only)
Monophonic mode, input at L-CH only. Speaker impedance > 8-ohm.
Speaker(+) connected to L+, speaker(-) connected to R+ output.
will * q + >
- AMPLIFIER. L~CH
47 ' E
GND '
n-cu © >
AMPLIFIER, R-CH
DIAGRAM 3
DIAGRAM 4 - BRIDGE MODE, BALANCED MODE (XLR input only)
Monophonic mode, input at L-CH only. Speaker impedance > 8-ohm.
Speaker(+) connected to L +, speaker(-) connected to R + output.
AMPLIFIER. R-CH
DIAGRAM 4
13
