Mitsubishi dd 8050 service manual
This is the 47 pages manual for mitsubishi dd 8050 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from mitsubishi dd 8050 service manual (Ocr-read)
Page 1
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
Page 2
1-1-1 E5932SP SPECIFICATIONS NOTES: 1. All Items are measured without pre-emphasis unless otherwise specified. 2. Power supply : AC120 V 60 Hz 3. Load imp. : 100 k ohm 4. Ambient Temperature : +25 °C ITEM CONDITIONS UNIT NOMINAL LIMIT 1. Video Output 75 ohm load Vpp 1.0 ± 0.1 2. Optical Digital Out dBm -18 3. Audio (PCM) 3-1. Output Level 1 kHz 0 dB Vrms 2.0 3-2. S/N dB 120 3-3. Freq. Response DVD fs=48kHz ± 0.5dB Hz 20~22 k CD fs=44.1kHz ± 0.5dB Hz 20~20 k 3-4. THD+N DVD 1 kHz 0dB % 0.004 CD 1 kHz 0dB % 0.0045
