Mitsubishi dd 4030 service
This is the 40 pages manual for mitsubishi dd 4030 service.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from mitsubishi dd 4030 service (Ocr-read)
Page 1
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories. "DTS" and "DTS Digital Out" are trademarks of Digital Theater Systems Inc.
Page 2
1-1-1DVDSP SPECIFICATIONS NOTES: 1. All Items are measured without pre-emphasis unless otherwise specified. 2. Power supply : AC120 V 60 Hz 3. Load imp. : 100 K ohm 4. Room ambient : +25 °C ITEM CONDITIONS UNIT NOMINAL LIMIT 1. Video Output 75 ohm load Vpp 1.0 2. Coaxial Digital Out mVpp 500 3. Audio (PCM) 3-1. Output Level 1kHz 0dB Vrms 2.0 3-2. S/N dB 110 3-3. Freq. Response DVD fs=48kHz 20~22kHz dB ± 2 CD fs=44.1kHz 20~20 kHz dB ± 2 3-4. THD+N 1 kHz 0dB % 0.005
